Operation
AUTO/MANUAL/OFF
Feature
AUTO Activates fully automatic operation. Green LED illuminates to verify system is in AUTO. Transfer to standby
power occurs if utility power fails. Functionality of exercise timer is enabled, if set.
MANUAL Cranks and starts engine. Blue LED illuminates to verify system is in MANUAL. Transfer to standby power
occurs if utility power fails. Functionality of exercise timer is disabled.
OFF Shuts down engine, if running. Red LED illuminates to verify system is in OFF. Transfer to standby power
does not occur if utility power fails.
Menu Navigation
See Figure 4-2.
Feature
HOME Screen System returns to Home screen if control panel is not used for five minutes. Screen normally displays a sta-
tus message, such as Ready to Run (AUTO) or Switched to OFF (OFF), and total Hours of Protection. If an
active alarm/warning condition occurs, the associated Alarm/Warning message is displayed. To clear
Alarm/Warning message, press OFF on control panel, followed by ENTER. In the event of multiple Alarms/
Warnings, next message is then displayed. The highest priority alarm is always displayed first.
Display Backlight Normally off. If operator presses any button, backlight will automatically light and remain on for 30 seconds.
MAIN MENU Allows operator to navigate software using up arrow, down arrow, ENTER, and ESCAPE. MAIN MENU can
be accessed from any sub menu by consecutively pressing ESCAPE. Each time ESCAPE is pressed, the
preceding menu is displayed. MAIN MENU is reached when System, Date/Time, Battery, and Sub-Menus
are displayed.
SUB-MENUS Sub-Menus screen includes HISTORY, MAINT, EDIT, and DEALER menus.
HISTORY HISTORY screen includes an alarm log and run log. Alarm log displays the last 50 alarm events. Run log
displays the last 50 operational events.
MAINTENANCE Includes Run Hours, Maintenance Log, and Schedule. Run Hours displays cumulative hours on engine.
MENU Maintenance Log displays the last service warnings and service completions. Schedule displays when the
next scheduled maintenance interval warning will occur.
EDIT MENU Includes Language, Current Date/Time, Exercise Settings, Firmware Update, Startup Delay, and Warm up
Time. All of these settings are adjustable without a password.
DEALER MENU Includes password protected settings and can be adjusted by an IASD during installation or a service visit.
ESCAPE Used to abort a routine or return to the preceding menu.
ENTER Used to make a selection or save an entry.
UP ARROW DOWN Used to move forward or backward from menu to menu, or to scroll forward or backward (increment or dec-
ARROW rement) through available selections.
NOTE: Pressing the control panel illuminates the backlight for 30 seconds. The backlight also illuminates for 30 seconds whenever
an active Alarm/Warning message is displayed.
For operation instructions of the Power Zone 410, see the technical manual.
