DIAGNOSTIC
REPAIR
MANUAL
50/60 Hz GC/RS/XC/XG/XP//HL/XT
and XT-EFI Series Portable Generators
60 HZ MODELS:
RS5500
XC6500
RS7000E
XC6500E
XC8000E
P O R T A B L E G E N E R AT O R S
XG4000
XP4000
XG5600
XP6500E
XG6400
XP8000E
XG6500
XP10000E
XG7000E
XG10000E
Important Note: Always use the unit specific Schematics and
Wiring Diagrams for troubleshooting.
50 HZ MODELS:
XT8000E
XG5600E
XT8000EFI
XG6400E
GC8100
HL6500E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT-EFI Series and is the answer not in the manual?

Questions and answers

Related Manuals for Generac Power Systems XT-EFI Series

Summary of Contents for Generac Power Systems XT-EFI Series

  • Page 1 DIAGNOSTIC REPAIR MANUAL 50/60 Hz GC/RS/XC/XG/XP//HL/XT and XT-EFI Series Portable Generators 60 HZ MODELS: 50 HZ MODELS: RS5500 XC6500 XG4000 XP4000 XT8000E XG5600E RS7000E XC6500E XG5600 XP6500E XT8000EFI XG6400E XC8000E XG6400 XP8000E GC8100 XG6500 XP10000E HL6500E XG7000E XG10000E Important Note: Always use the unit specific Schematics and Wiring Diagrams for troubleshooting.
