Activation and Startup
Evolution Control Panel
The Evolution control panel is located behind the viewing window at the rear of the unit.
Figure 3-3.
o
OFF
7.5 amp fuse and USB port cover
A
Control panel
B
Generator main line circuit breaker (MLCB) (gen-
C
erator disconnect)
D LCD
UP arrow (+)
E
F Enter
16
C
PUSH TO TRIP
L
K
Figure 3-3. Generator Control Panel for RD Units
B D
E
J
H
DOWN arrow (-)
G
Escape
H
OFF (red LED)
J
MANUAL (blue LED)
K
AUTO (green LED)
L
