CHARACTERISTICS:
The "HD67414" series are rugged devices used to interface CAN devices with Modbus TCP Slaves.
With his particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal,
vertical, oblique).
It is possible to have the device varnished or totally resined and also in both cases with "Mini-Fit®" connectors or "AMP SuperSeal 1.5"
connectors. If is resined, the enclosure, like the "AMP SuperSeal 1.5" connectors, is waterproof.
All the four series have these characteristics:
Triple 4kV isolation between Power Supply / Ethernet / CAN;
Varnished / Resined (optionally);
Wide power supply input range: 8...26V AC | 10...40V DC;
Mini-Fit® / AMP SuperSeal 1.5 connectors;
Metal enclosure with fixing lugs;
Possibility to use Metal hose clamps for fixing it without using lugs;
Microprocessor for data control;
Wide temperature range: -40°C / 105°C (-40°F / 221°F).
CONFIGURATION:
You need Compositor SW67414 software on your PC in order to perform the following:
Define the CAN frames read from Converter;
Define the CAN frames write from the Converter;
Define the Modbus TCP requests in read;
Define the Modbus TCP requests in Write;
Update the device.
