The safety alert symbol is used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or property damage.
Read this manual and follow all Safety Rules and Operating Instructions before using this product.
SAFETY AND GENERAL INFORMATION
Save these instructions. For your safety, read, understand, and follow the information provided with and on this device
before using. The owner and/or operator should have an understanding of the device, its operating characteristics and
safety operating instructions before operating the equipment. The owner and/or operator should be aware that use and
repair of this product may require special skills and knowledge. Instructions and safety information should be read to
and discussed with the operator in the operator's native language, making sure that the operator comprehends their
contents, before use of this equipment is authorized. If any doubt exists as to the safe and proper use of this device,
remove from service immediately.
Inspect before each use. Do not use if abnormal conditions such as cracked welds, damaged, loose or missing parts
are noted. Any equipment that appears damaged in any way, is found to be worn, or operates abnormally should be
removed from service until repaired. If the equipment has been or is suspected to have been subjected to an abnormal
load or shock, immediately discontinue use until inspected by a factory authorized repair facility (contact distributor
or manufacturer for list of authorized repair facilities). It is recommended that an annual inspection be made by an
authorized repair facility. Labels and operator's manuals are available from the manufacturer.
• Maintain the jack in good operational condition. Keep it clean for best and safest performance.
• The maximum load is 50 tons. DO NOT exceed this rated capacity.
• Use this jack for lifting purposes only. DO NOT use it for any other purpose.
• Keep children and unauthorized persons away from the work area.
• Remove poorly fitting clothing. Remove ties, watches, rings and other loose jewelry, and contain long hair.
• Wear ANSI approved safety goggles when operating the jack.
• Keep proper balance and footing, wear nonslip footwear and do not overreach.
• Only use this jack on a surface that is stable, level, dry, not slippery, and capable of sustaining the load.
• Keep your working surface clean, tidy and free from unrelated materials. Ensure that there is adequate lighting.
• Before lifting a vehicle, apply the emergency brake and chock all wheels in front and behind.
• Immediately after lifting, support the load with appropriate supporting equipment such as jack stands of adequate
capacity. DO NOT work under a load which is supported only by a jack.
• Before lowering load ensure that there are no obstructions underneath and that all persons are standing clear.
• DO NOT attempt to move the load while on the jack. The jack must only be used in a static position for lifting and
lowering loads. Ensure that the load remains stable at all times.
• DO NOT use the jack if damaged, any suspect parts are noted or it has been subjected to a shock load.
• DO NOT operate the jack when you are tired or under the influence of alcohol or drugs.
• DO NOT allow untrained persons to operate the jack.
• DO NOT make any modifications to the jack.
• DO NOT use brake fluid or any other improper fluid and avoid mixing different types of oil when adding hydraulic oil.
Only a good quality hydraulic jack oil can be used. We recommend Mobil DTE-13M or equivalent.
• DO NOT expose the jack to rain or any other kind of bad weather.
• If the jack needs to be repaired and/or there are any parts that need to be replaced, have it repaired by authorized
technicians and only use the replacement parts supplied by the manufacturer.
!
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all
possible conditions and situations that may occur. It must be understood by the operator that common sense and and
caution are factors which cannot be built into this product, but must be supplied by the operator.
PRODUCT DESCRIPTION
Hydraulic Axle Jacks are designed to lift, but not support, rated capacity partial vehicle loads consisting of
one end of a vehicle. Immediately after lifting, support loads with a pair of appropriately rated jack stands.
