MAINTENANCE

Important:
potential for sudden and immediate loss of load. We recommend Mobil DTE-13M or equivalent.
Adding/ Changing Oil
NOTICE:
3. Set jack in its upright, level position.
4. Fill with oil. Proper oil level is just below the rim of the opening. Reinstall the oil filler plug.
5. Perform Bleeding/Venting Trapped Air procedure (page 4).
Lubrication
A periodic coating of light lubricating oil to pivot points, axles and hinges will help to prevent rust and assure that
wheels move freely and the pump functions smoothly. To help ensure trouble free operation, an in line air dryer and
oiler is recommended.
Cleaning
Periodically check the ram for signs of rust or corrosion. Clean as needed and wipe with an oily cloth.
Note: Never use sandpaper or abrasive material on ram surfaces!
Storage
When not in use, store the jack with saddle fully lowered.

TROUBLESHOOTING

Symptom
Jack will not li
Jack will li , but cannot maintain
pressure
Jack will not lower a er unloading
Poor li performance
Will not li to full extension
Possible Causes
1. Release valve not ghtly closed
2. Air trapped in system
3. Weight capacity exceeded
4. Air supply inadequate
5. Hydraulic unit malfunc on
1. Release valve not ghtly closed
2. Release valve is broken
3. Hydraulic unit malfunc on
1. Oil reservoir is over lled
2. Release valve is broken
3. Moving parts got stuck
1. Low uid level
2. Air trapped in system
Low uid level
d supply at least once per year.
plug.
r.
l regulations.
Corrective Action
1. Ensure release valve (#P1) ghtly closed
2. Follow Bleeding/Ven ng Trapped Air procedure on page 4
3. Consider higher capacity jack
4. Ensure adequate air supply
5. Discon nue to use the product, call your point of purchase for
solu on
1. Ensure release valve (#P1) ghtly closed
2. Replace the release valve (#P1)
3. Discon nue to use the product, call your point of purchase for
solu on
1. Drain excessive uid to proper level
2. Replace the release valve (#P1)
3. Clean and lubricate moving parts
1. Follow adding and changing oil procedure on page 6
2. Follow Bleeding/Ven ng Trapped Air procedure on page 4
Follow adding and changing oil procedure on page 6
