Crestron Digital Graphics Engine 1000 Product Manual page 10

USB
LAN PoE+
24 V 1.25A
Controls and Indicators
PWR
RESET
SETUP
ONLINE
HDMI IN/OUT
LAN PoE+
Power
Power over Ethernet
Power Pack (Sold
Separately)
Power Consumption
Environmental
Temperature
Humidity
Heat Dissipation
Construction
Chassis
Mounting
Dimensions
Height
Width
Depth
Weight
1.9 lb (0.86 kg)
Compliance
Regulatory Model: M202011001
Notes:
7 • DGE-1000
(2) USB Type A connectors; USB 2.0 host port for USB conferencing peripheral; USB
3.0 host port for USB conferencing peripheral; (1) USB Type B connector; USB 3.0
device port for computer console
(1) 8-pin RJ-45 connector; 100Base-TX/1000Base-T Ethernet port and PoE+ Class 4
(1) 2.1 x 5.5 mm DC power connector; 24VDC power input;
sold separately
(1) Green LED, indicates operating power supplied via the local power pack or PoE+
(1) Recessed push button for hardware reset
(1) Red LED and (1) recessed push button for onscreen IP address display
(1) Green LED, indicates control system connection
(2) Green LEDs, indicate HDMI signal presence at the HDMI input/output
(2) LEDs, green LED indicates Ethernet link status, amber LED indicates Ethernet
activity
IEEE 802.3af Class 4 Powered Device
Input: 100-240VAC, 50/60 Hz; Output: 1.25A @ 24VDC; Model:
14 W (typical)
32° to 104°F (-0° to 40° C)
10% to 90% RH (non-condensing)
47.8 BTU/hr
Metal, black finish, with (2) integral mounting flanges, vented sides
Freestanding, surface mount, or attach to a single rack rail
1.26 in. (33 mm)
7.40 in. (188 mm)
6.54 in. (166 mm)
PW-2412WU power pack
PW-2412WU
Product Manual — Doc. 9462A
