Crestron Digital Graphics Engine 1000 Product Manual page 9

Streaming Decoder
Video Formats
Audio Formats
Bitrates
Resolutions
Video
Input Signal Types
Output Signal Types
Maximum Input
Resolutions
NOTE: Interlaced video is not supported. All video inputs will be scaled to the selected HDMI.
HDMI Output Resolutions
NOTE: All video inputs are scaled to the selected HDMI output resolution.
Audio
Input Signal Types
Output Signal Types
Input/Output Format
Connectors and Card Slots
IR
NOTE: IR port 2 is not used. IRP2 emitter is sold separately.
COM
AUDIO OUT
HDMI Input
HDMI Output
Product Manual — Doc. 9462A
H.264 and H.265 (MPEG-4 part 10 AVC, MJPEG)
AAC stereo
Up to 20 Mbps
Up to 1080p30
HDMI (DVI and dual-mode DisplayPort™ signal compatible
HDMI (DVI compatible 4
HDMI Input: 1920x1080@60Hz (HD 1080p60);
1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1280x800@60Hz
1366x768@60Hz 5 , 1440x900@60Hz
1680x1050@60Hz 5 , 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60),
3840x2160@30Hz(2160p30) 3840x2160@50Hz(2160p50) 3840x2160@60Hx(2160p)
HDMI (dual-mode DisplayPort compatible
HDMI
2 channel LPCM
(1) 2-pin 3.5 mm detachable terminal block; IR/Serial output port for display device
control; IR output up to 1.1 MHz; 1-way serial TTL/RS-232 (0-5V) up to 19200 baud
(1) 5-pin 3.5 mm detachable terminal block; Bidirectional RS-232 port for display
device control; Up to 115.2k baud, hardware and software handshaking support
(1) 5-pin 3.5 mm detachable terminal block;
Balanced/unbalanced stereo line-level audio output;
Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced;
Output Impedance: 200 ohms balanced, 100 ohms unbalanced
(1) HDMI Type A connector;
HDMI digital video/audio input;
(DVI & Dual-Mode DisplayPort compatible )
(1) HDMI Type A connector; HDMI digital video/audio output (DVI compatible2)
)
5 , 1600x900@60Hz
4 )
4 )
5 ,
6 , 1600x1200@60Hz,
DGE-1000 • 6
