- Page 1 TANGO FRAMING PR-6611 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
Any future technical change in the user manual won’t be with any notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty... -
Page 3: Safety And Warnings
SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Flames Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. -
Page 4: Instructions
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord supplied through the safety cord holes for safety support. ●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from power mains. ●After running for 5minutes under steady temperature, the temperature of the housing of the projector is 55℃.After stable operation , its temperature is 70℃. -
Page 5: Appearance
3.APPEARANCE HEAD SUPPOR BASE 4.INSTALLATION SAFETY CORD WARMING SUPPOR For safety, please run the safety cords through safety holes and ensure they are locked well. ●RIGGING Take 2 clamps and 2 safety cords out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. - Page 6 Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. Note: If projectors are connected in series, please connect POWERIN port of the 1 projector with the Power Mains, then connect its POWER OUT with POWER IN of the 2...
-
Page 7: Setup And Configuration
the output socket on the last projector in the chain. The connections are illustrated below. DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 5.SETUP AND CONFIGURATION... -
Page 8: Operation Menu
panel will be on, meaning wireless control function is activated. Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press “Enter” for the menu of Unlink Wireless under the upper level menu of Config Settigns . STAND-ALONE MODE ●... - Page 9 WTOX (Wireless to XLR) MORS Slav Master/Slave (Slave) （Default：SLAV） Mast (Master) DISM Dela Display Mode (Off after delay) （Default：Off after delay） (Always on ) DimA (All Dimmer) 0-128 UNLW (Unlink wireless ) ResL (Reset lamp hours) ResU (Reset user memory ) ResO (Reset options ) FactS...
- Page 10 (RDM version) (RDM Device label) Co1H (Magnet sensor for color wheel 1) Co2H (Magnet sensor for color wheel 2) EFFH (Magnet sensor for effect wheel ) RG H (Magnet sensor for rotating gobo wheel) GR H (Magnet sensor for gobo rotation) FOCH SENE (Magnet sensor for focus )
- Page 11 Pri1 Prism1 Have Prism in Stop Pr1R Rota Prism 1 rotates Forward rotation Reve Reverse rotation Pri2 Prism 2 Have Prism in Stop Pr2R Rota Prism 2 rotates Forward rotation Reve Reverse rotation EffE Have Effect wheel Effect wheel in Stop Ef1R Rota...
-
Page 12: Dmx Protocol
User memory Stro /Strobe 0-255 Dimm /Dimmer 0-255 DimS / Dimmer speed 0-255 Co1W/ color wheel 1 0-255 Co2W/ color wheel2 0-255 CH6 R-G/rotating gobo wheel 0-255 G-R/ gobo rotation 0-255 FRM/framing module macro 0-255 FR1L/Framing blade 1 left 0-255 CH10 FR1R/Framing blade 1 right 0-255... - Page 13 038-046 color2（Green） 047-055 Color2/color3 056-064 Color3（Orange） 065-073 Color3/Color4 Color4（Magenta ） 074-082 083-091 Color4/Color5 092-100 Color5（Red） 101-109 Color5/Color6 110-118 Color6（High CRI） 119-127 Color6/White 128-191 Forward rotation from slow to fast 192-255 Reverse rotation from slow to fast 000-010 White 011-019 White/color1 020-028 Color1（Dark cyan）...
- Page 14 128-156 Forward rotation from slow to fast 157-185 Reverse rotation from slow to fast 186-196 Shake effect 1 from slow to fast 197-208 Shake effect 2 from slow to fast 209-220 Shake effect 3 from slow to fast 221-232 Shake effect 4 from slow to fast 233-244 Shake effect 5 from slow to fast 245-255...
- Page 15 blade 3 left 000-255 16bit Framing 000-255 Linear change 0-100% blade 3 000-255 16bit right 000-255 Linear change 0-100% Framing blade 4 left 000-255 16bit 000-255 Linear change 0-100% Framing blade4 right 000-255 16bit 000-016 White Prism1 017-255 Prism 1 in 000-128 Prism indexing(0-540degrees ) 129-191...
-
Page 16: Technical Data
Focus 000-255 Linear focus 0-100% Focus in 16 000-255 Focus in 16 bit 000-047 Reserved Control 048-255 Reset(Stop for 5S) TECHNICAL DATA ELECTRIC PARAMETERS ，50/60Hz 190V~240V AC Input voltage Input power 800W@220V Maximum current: 3.7A Power factor:PF>0.9 THE SPECIFICATIONS OF THE LIGHT SOURCE Power 600W Color temperature... - Page 17 FOCUS DMX linear Focusing DIMMER 0-100% Linear adjustment STROBE Double shutter blades, 0.3~25 F.P.S BEAM ANGLE linear zoom 8° ～ 52° with 16 bit function CONTROL DMX512, 5 pin interfaces(Optional 3-pin interfaces) RDM control protocol Ethernet Control 26channels in short mode, 29channels in standard mode and 38channels in extended mode Master/Slave synchronized mode Stand-alone mode Self-test mode...
- Page 18 SIZES MOUNTING DIAGRAM LIGHT OUTPUT 8°Lux 52°Lux 0 DISTANCE (m) 0 8°DIAMETER(m) 0 52°DIAMETER(m) 0...
-
Page 19: Circuit Diagram & Pcb Connections
9. CIRCUIT DIAGRAM & PCB CONNECTIONS ● CIRCUIT DIAGRAM PR-6611电气接线图... - Page 20 ● PCB CONNECTIONS MAIN BOARD Name Signal input Power input Thermal sensor (Reserved ) PWM output(Reserved ) Signal output Wireless （Reserved） LED DRIVER BOARD Name LED Output1 LED Output2 LED Output3 LED Dimmer power input LED MODULE CONNECTION Name LED module LED driver LED driver LED driver...
- Page 21 7-CHANNEL BOARD Name Motor driver output Power Signal input Signal output 11-12 Reserved 13-19 Hall sensor input Reserved 8-CHANNEL BOARD (ZOOM &FOCUS) Name Motor driver output Power Signal input Signal output 12-13 Reserved 14-19 Hall sensor input 20-21 Reserved FRAMING MODULE Motor driver output Power input Signal input...
-
Page 22: Component Order Codes
10. COMPONENT ORDER CODES NAME CODE NO. QTY. NOTE SWITCHING POWER SUPPLY 192010207 SWITCHING POWER SUPPLY 6190000004 LED MODULE 150020313 LED MODULE FAN 030060109 TURBO FAN FOR COLOR WHEEL 030060098C 030060052A TURBO FAN FOR BASE LED DRIVER FAN 030060084 FAN FOR LENS 030060050A FOCUS MOTOR 030040213A... - Page 24 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 6320000131...
