This product manual contains important information about the safe installation and use of this lighting fixture.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
NAME: Pro Stage 348
MODEL: PR-8920
PR LIGHTING LTD.
http://www.pr-lighting.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PR Lighting PR-8920
Summary of Contents for PR Lighting PR-8920
- Page 1 NAME: Pro Stage 348 MODEL: PR-8920 This product manual contains important information about the safe installation and use of this lighting fixture. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
INDEX SAFE USAGE OF THE LIGHTING FIXTURE …………………………………………………………………. INSTALLING THE LIGHTING FIXTURE ……………………………………………………………………... CONTROL SYSTEM AND POWER CONNECTIONS ………………………………………………………..DMX TERMINATOR ………………………………………………………... ……………………………..SETUP OPTIONS- LIGHTING FIXTURE CONFIGURATION …………………………………………………. TO SET THE DMX START ADDRESS ………………………………………………………... ……………… OPERATION MENU ………………………………………………………... ……………………………..DMX PROTOCOL ………………………………………………………... - Page 3 The lighting fixture can be only used indoors, IP20. The lighting fixture is not designed or intended to be mounted directly on to inflammable surfaces. The lighting fixture is only intended for installation, operation and maintenance by qualified personnel. Do not project the beam onto inflammable surfaces, minimum distance is 5m. Avoid direct exposure to the light from the lamp.
-
Page 4: Installing The Lighting Fixture
INSTALL THE LIGHTING FIXTURE When the lighting fixture is used, put it on a flat surface or hang it. Make sure it is steady and secured. When the lighting fixture is used at a high place, as the figure above, move the support to the top of the lighting fixture, connect a lamp hook to the mounting hole reserved in the support by screws, and then hang the hook to mounting bar. -
Page 5: Dmx Terminator
Note: Care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. The body of the plug is not connected in any way. The device accepts digital control signals in protocol DMX512 (1990). Maximum 32 units can be connected in series by 3-pin signal cable. -
Page 6: To Set The Dmx Start Address
Press button FUNC, it will return to the upper menu one by one or browse through the main menu. TO SET THE DMX START ADDRESS Each device must be given a DMX start address so that the correct lighting fixture responds to the correct control signals. This DMX start address is the channel number from which the lighting fixture starts to “listen”... -
Page 7: Operation Menu
DMX PROTOCOL CHANNELS FUNCTION DESCRIPTION Dimmer 000-255 Linear Dimming from dark to light White 000-255 Linear Dimming from dark to light 000-255 Linear Dimming from dark to light Green 000-255 Linear Dimming from dark to light Blue 000-255 Linear Dimming from dark to light No effect Strobe 001-255... -
Page 8: Indication Of Led Display
INDICATION OF LED CHARACTER DMX signal OK DMX Indication No DMX signal Flash Parameter or Value not saved, please press Display Information ENTER T to save MAINTENANCE To prolong the life of the lighting fixture, it is very important to do the maintenance work. Cooling fans must be cleaned once every 15days and external lens cleaned periodically for an optimum light output. -
Page 9: Technical Data
TECHNICAL DATA VOLTAGES: 100-240V AC，50/60Hz POWER CONSUMPTION: 100W LED: Quantity 48 （R:12＋G:12＋B:12＋W:12） Manufacturers Rated LED Life 50000 Hours COLOURS: RGBW linear color mixing with Macro COLOR TEMPERATURE CORRECTION： Linear color temperature correction from 3200K to 10000K DIMMER: 0-100% linearly adjustable Light Source Luminous Flux 2100 lm STROBE:... - Page 10 SIZES: Light Output （ ） vertical direction 10/14...
-
Page 11: Electrical Diagram
Electrical Diagram 11/14... -
Page 12: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 3-PIN CONTROL CABLE 242810033 200W POWER SUPPLY 190010122 K18N-UP200S58 LAMP BOARD 230060162 RGBW 48*3W MAIN CONTROL BOARD 230060171 LED 4 CHANNEL DRIVER BOARD 230060174 12/14... - Page 13 13/14...
-
Page 14: Back Cover
PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020131 Version: 20130513 14/14...
