XR 200
BEAM
PR-2202
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR 200 BEAM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XR 200 BEAM

Summary of Contents for PR Lighting XR 200 BEAM

  • Page 1 XR 200 BEAM PR-2202 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...

  • Page 2: Table Of Contents

    INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE OPERATION MENU DMX PROTOCOL INDICATION OF LED DIGITAL TUBE MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN...

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check if there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.
  • Page 4 INSTALL THE PROJECTOR SAFETY CORD WARNING CLAMP To pass 1 SAFETY CORD through 2 holes for safety CONTROL PANEL HANDLE Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp.

  • Page 5: Control Connections

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector.

  • Page 6: Setup Options-Projector Configuration

    “listen” to the digital control information being sent out from the controller. XR 200 BEAM has 3 DMX modes. There are standard mode ,short mode and extended mode. For example standard mode have 14 channels, so set the No.

  • Page 7: Stand-Alone Mode

    STAND-ALONE MODE Operate the projector without connecting a controller, enable the master mode in the operation panel, the projector will run in Stand-Alone mode automatically. MASTER/SLAVE MODE Without using a controller, many projectors can run synchronously in the Master/Slave mode by linking them with each other.

  • Page 8: Operation Menu

    OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL AddR (1~499) Reset Are you sure STd 14 (DMX Mode Standard) SHRT 10 (DMX Mode (DMX Mode Short) ,Default: STD) EXT 16 (DMX Extended Mode) ByControlChanne Lamp Control Set (By Control Channel) (Lamp Control CNFG ByPowerOn...
  • Page 9 Mode 1 Mode 2 (White) Cw1-CW14 (Color Wheel1-Color Wheel14) FORw Color Wheel (Rotation) STOP (Rotation Stops) REVE (reverse Rotation) (White)_ Gobo1-Gobo17 Fixed Gobo Wheel Rotation Manual Test Reverse Rotation Shake Effect 1-10 Effect 1 Effect Wheel Effect 2 Effect 3 Stop Effect Wheel Rotation Rotation...
  • Page 10 0-255 (Effect Wheel) 0-255 (Effect Wheel Rotation) 0-255 (Focusing) 0-255 (Pan Location) 0-255 (Tilt Location) CH10 0-255 (Pan and Tilt Speeds) CH11 0-25 Seconds Scene hold time Turn Lamp On Lamp Manual Control Turn Lamp Off Remark: 1. In the synchronous control of multiple projectors parameters can be transmitted from the master including: DMX mode, display setting, operation mode(user memory);...

  • Page 11: Dmx Protocol

    DMX PROTOCOL Short Standard FUNCTION DESCRIPTION mode mode Strobe Open 000-015 Strobe from Slow to Fast 016-255 Dimmer From dark to bright 000-255 000-011 White 012-015 White+Color 1 016-019 Color 1 020-023 Color 1+Color 2 024-027 Color 2 028-031 Color 2+Color 3 032-035 Color 3 036-039...
  • Page 12 008-015 Gobo 1 016-023 Gobo 2 024-031 Gobo 3 032-039 Gobo 4 040-047 Gobo 5 048-055 Gobo 6 056-063 Gobo 7 064-071 Gobo 8 Fixed Gobo 072-079 Gobo 9 Wheel 080-087 Gobo 10 088-095 Gobo 11 096-103 Gobo 12 104-111 Gobo 13 112-119 Gobo 14...
  • Page 13 Tilt Fine Tilt in 16 bit precision 000-255 Pan & Tilt Pan & Tilt Speed from Fast to Slow 000-255 Speeds Reserved 000-031 Lamp Off (stop in DMX value for 2 s) 032-063 Reserved 064-095 Lamp On ( stop in DMX value for 2 s) 096-127 Control Reserved...
  • Page 14 120-123 Color 14 124-127 Color 14/White 128-255 Rotation （From slow to Fast） Open 000-003 Strobe from Slow to Fast Strobe 004-103 104-255 Open Dimming 000-255 From dark to Bright 000-003 White 004-007 Gobo 1 008-011 Gobo 2 012-015 Gobo 3 016-019 Gobo 4 020-023...
  • Page 15 128-255 Eight-facet Prim Stop 000-127 Rotation （From Fast to Slow） 128-190 Prism Rotation Stop 191-192 Reverse Rotation （From slow to Fast） 193-255 0-127 White CT Filter 128-255 CT Filter 0-127 White Frost Filter 128-255 Frost Effect focusing 0-255 Linearly focusing Pan(0°~540°) 000-255 Pan Fine...

  • Page 16: Indication Of Led Digital Tube

    INDICATION OF LED DIGITAL TUBE DMX signal OK Decimal point of the first digital tube No DMX signal Master / slave signal is OK Decimal point of the third digital tube No master / slave signal When setting master mode Decimal point of the fourth digital tube When setting slave mode Parameters that LED digital tubes display...
  • Page 17 Check the fuse on the power socket. The projector doesn’t switch on Replace the lamp. The lamp comes on but the projector doesn’t Make sure that the fixture’s start address is right respond to the controller Replace or repair the XLR singal cable. The projector only functions intermittently Make sure the fan is working well or fans and their filters not blocked Make sure the lamp is within its life limit...

  • Page 18: Technical Data

    TECHNICAL DATA VOLTAGES: 100V/200V/220V/230V/240V AC，50/60Hz POWER CONSUMPTION: 280W@220V LAMP: PHILIPS MSD Platinum 5R Colour Temperature 8000°K 2000 Manufacturers Rated Lamp Life COLORS: 1 Color Wheel 14 dichroic colour filters plus white variable speed and bi-directional rainbow effect linear colour changing is available GOBOS: 1 Fixed gobo wheel : 17 interchangeable gobos+ white...
  • Page 19 10 channels in short mode, 14channels in standard mode, 16modes in Extended Mode Self-test mode OTHER FUNCTIONS: Adjustable Pan & Tilt speed Fixture and lamp usage time display Modular construction for easy maintenance DMX512 wireless receiver DMX512 wireless transmitter (optional) HOUSING: Composite plastic, IP20 Power driven water proof cover, optional, water proof system control by DMX, IP44...
  • Page 20 VLED VLED...

  • Page 21: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 5R BALLAST 040070109 100070026 5R LAMP 200W POWER SWITCH 190010133 190010116 400W POWER SWITCH 270041065 T20A/250V 6.3*32mm FUSE 290151322 HTD-531-3M PAN DRIVER BELT TILT DRIVER BELT 290151331 HTD-399-3M 290151255 HTD-270-3M PRISM WHEEL BELT 290151310 72MXL FOCUSING BELT...
  • Page 22 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020181 Version: 20130621(Preliminary） 22/22...
