VEVOR BY10650Z Original Instruction

VEVOR BY10650Z Original Instruction

Brushless dc motor
Hide thumbs Also See for BY10650Z:

Advertisement

Table of Contents

Technical Support and E-Warranty Certificate www.vevor.com/support
Brushless DC motor
Model: BY10650Z
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BY10650Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VEVOR BY10650Z

Summary of Contents for VEVOR BY10650Z

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support Brushless DC motor Model: BY10650Z We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.

  • Page 2: Brushless Dc Motor

    This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 3: Safety Precautions

    Safety precautions 1.1Safety advisory warning Please read carefully before operation. Be sure to read all safety warnings and all instructions before operating the motor. Failure to comply with warnings and instructions may result in electric shock, fire or serious injury. If you encounter problems, please communicate with customer service in time to solve, your satisfaction is our service purpose.
  • Page 4 2) It is recommended to use lead-acid batteries. Lithium batteries can also work (note that the battery voltage and battery power match the kit power). The recommended battery capacity is 12AH-20AH. The battery voltage needs to be consistent with the motor kit voltage, allowing an over voltage range of +10%. The positive and negative terminals of the power supply must be connected correctly (the positive terminal is connected to the thick line of the controller in red, and the negative terminal is connected to the thick line of the controller in black).
  • Page 5 TECHNICAL INFO PERFORMANCE PARAMETERS OF BY10650Z MOTOR Rated Voltage 48V DC Max Wattage 500W Rated Speed 450RPM Gear ratio Rated Current No-load Speed 3100RPM（510 RPM after gear reduction） No-load Current ≤5A Motor Efficiency ≥85% Sprocket Number 420-13T M10*1.5 (Heat 80℃ for 1-2 minutes,...

  • Page 6: Configuration List

    CONFIGURATION LIST 1. Motor 2. The controller 3. Hardware tools INSTALLATION PROCEDURE Step 1 Same color on both sides Step 2 Voltage: DC48V-54V 1.Red:48v+ 2.Black:54V- Positive and negative can not be connected wrong, otherwise it will burn the controller. There may be a slight spark when connecting, which is a normal phenomenon of power-on.
  • Page 7 Instructions for other functions Please purchase the necessary accessories by yourself Reverse Key:Switch brown and black short, reverse speed is only 40%. Electric lock: The orange and red power cables of the controller are connected to 48V+ batteries Brakes:Connect the electronic brake to realize the braking power off function.

  • Page 8: Correct Disposal

    COMMON PROBLEMS AND REMEDIES Phenomenon: Motor does not work Reason: Battery The battery is too low and does not reach the required operating voltage Solution: 1. Select a battery with the corresponding operating voltage ; 2. Check whether each plug-in is connected correctly and whether the connected terminals are connected reliably, so as to avoid failure to work normally due to incorrect connection or poor contact.
  • Page 9 WARNING: Changes or modifications to this product not expressly approved by the party.responsible for compliance could void the user's authority to operate the product. Note: This product has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules, These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 10 Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN. Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 YH CONSULTING LIMITED. C/O YH Consulting Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4AX E-CrossStu GmbH...
  • Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
