Technical Support and E-Warranty Certificate www.vevor.com/support
Brushless DC motor
Model: BY1020D
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR BY1020D
Summary of Contents for VEVOR BY1020D
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support Brushless DC motor Model: BY1020D We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
- Page 3 Safety precautions 1.1Safety advisory warning Please read carefully before operation. Be sure to read all safety warnings and all instructions before operating the motor. Failure to comply with warnings and instructions may result in electric shock, fire or serious injury. If you encounter problems, please communicate with customer service in time to solve, your satisfaction is our service purpose.
- Page 4 2) It is recommended to use lead-acid batteries. Lithium batteries can also work (note that the battery voltage and battery power match the kit power). The recommended battery capacity is 12AH-20AH. The battery voltage needs to be consistent with the motor kit voltage, allowing an over voltage range of +10%. The positive and negative terminals of the power supply must be connected correctly (the positive terminal is connected to the thick line of the controller in red, and the negative terminal is connected to the thick line of the controller in black).
- Page 5 TECHNICAL INFO PERFORMANCE PARAMETERS OF BY1020D MOTOR Rated Voltage 48V DC Max Wattage 1800W Rated Speed 4500RPM Gear ratio 4N.m Rated Current No-load Speed 5300RPM No-load Current ≤6A Motor Efficiency ≥85% Sprocket Number T8F-9T M8*1.25Left-hand tighten the thread(Heat Screw thread 80 ℃...
-
Page 6: Configuration List
PERFORMANCE PARAMETERS OF BY15WF01-A Controller Parameter Numerical value Rated Voltage 48V DC Max Wattage 1800W Rated Current Brake BRAKE LOW LEVEL Under Voltage Protection Working Temperature -40℃~60℃ Size 176mm×90mm×50mm Weight 0.6KG CONFIGURATION LIST 1. Motor 2. The controller 3. Throttle 4. -
Page 7: Installation Procedure
INSTALLATION PROCEDURE Step 1 Same color on both sides Step 2 Voltage: DC48V-54V 1. Red: 48v+ 2. Black:48V- Positive and negative can not be connected wrong,otherwise it will burn the controller. There may be a slight spark when connecting, which is a normal phenomenon of power-on. - Page 8 Step 4 Controller integrated plug-in and cable connection Step 5 The electronic lock must be connected, you can use a two-wire electric door lock, you can also use a wire to short connect the red line and the yellow line Instructions for other functions Please purchase the necessary accessories by yourself 3 Speed: The default speed is...
- Page 9 With the reverse switch, the motor rotates in reverse, but the speed is 30% of the forward speed Brakes: Connect the electronic brake to realize the braking power off function. COMMON PROBLEMS AND REMEDIES Phenomenon: Motor does not work Reason: Battery The battery is too low and does not reach the required operating voltage Solution: 1.
-
Page 10: Correct Disposal
CORRECT DISPOSAL This product is subject to the provision of european Directive 2012/19/EU. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol. - Page 11 · Increase the distance between the product and receiver. · Connect the product to an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for assistance. Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN.
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
