Axminster WORKSHOP AW200BS Original Instructions Manual page 17

14
Replace the lower guard assembly.
15
Replace the lower guard front screw.
16
Lower the tension lever to re-tension the linisher belt.
17
Replace the lower guard side screw.
CHANGING THE ABRASIVE BELT/DISC
18
19
Replace the rear guard assembly.
20
Replace the linisher table (B) assembly.
Give the machine a 'quick' burst check ( i.e. quick ON-OFF)
to ensure everything is O.K. If everything is satisfactory,
continue with operation.
17
B
CLEAR ALL TOOLS AWAY FROM
THE WORK AREA. CONNECT THE
SANDER TO THE MAINS SUPPLY!
