H. Periodic Replacement Parts
The imagePROGRAF
replacement parts.
I. Maintenance Kit
Canon USA has prepared an imagePROGRAF iPF755/iPF750 Maintenance
Kit to help provide high durability of the printer and keep the operating costs
at a minimum. This Maintenance Kit should be installed at the interval listed in
the table below to reduce possible downtime. The printer has a built-in
counter for these consumable parts, which will display messages to notify the
user when the maintenance kit should be installed.
iPF 755/iPF750 Maintenance Kit Parts List (Table 12)
CARRIAGE UNIT
ENCODER SENSOR UNIT
LINEAR SCALE
PAD
MULTISENSOR UNIT
MIST FAN DUCT UNIT
MIST FAN
J. End-User Periodic Maintenance
In accordance with the user's manual, the end-user is expected to maintain
the following areas of the printer:
• Print head cleaning (using the operation panel)
• Replace print heads, ink tanks, and filters
• Clean ink mist and other substances around external covers and output
basket area (dry after wiping with a damp cloth)
K. Technician Maintenance Items
There are no periodic replacement parts or end-user periodic maintenance,
other than those described above, required for the imagePROGRAF
iPF755/iPF750.
imagePROGRAF iPF755/iPF750 Service Guide
Rev. 1
iPF755/iPF750
Description
imagePROGRAF iPF755/iPF750 Service Guide
does not
Counter Estimated Life
Error! Bookmark
Name (A0
Qty
not defined.
Sheets)
14,000
CR1 1
CR3 1 14,000
CR3 1 14,000
CR3 4 14,000
14,000
CR5 1
14,000
Mi 1
Mi 1 14,000
have any periodic
1
Part Number
QM3-5824-000
QM3-4574-000
QC3-1501-000
QC3-1514-000
QM3-5831-000
QM3-5853-000
QM3-5854-000
