D. Installation / Service Support Tools
The necessary tools to install these printers are in the Table below.
imagePROGRAF iPF755/iPF750 Installation Tools (Table 7)
Hexagonal wrench (Provided with the printer stand)
Cut sheet paper of A3 size or larger, or roll paper
Cutter
In addition to the standard tools used to service this device, the following
special tools, solvents, & oils should also be carried when servicing the
imagePROGRAF iPF755/iPF750.
Special Tools, Solvents, & Oils List (Table 8)
Tool/Description
Cover switch tool
Syringe
Tube
Grease (MOLYCOTE PG-641)
Grease (PERMALUB G2)
Silbon paper
Rubber gloves
Pen light
E. Consumables (Main Unit)
Consumables are materials consumed with regular use and cannot be
reused. Consumables should be replaced by The end-user or Service
Technician. Consumables include but are not limited to paper, chemicals and
ink.
A number of factors go into the approximate life expectancy of a consumable,
for example, in the case of ink yield, paper size and the amount of coverage
per page must be considered.
Note: All estimated life targets shown in the table below are estimates for
reference purposes only and are subject to change without notice. Actual
usage will vary.
Common Consumables List (Table 9)
Description
Print Head PF-04
Ink tank PFI-102 MBk
Ink tank PFI-102 Bk
Ink tank PFI-102 C
Ink tank PFI-104 M
Ink tank PFI-102 Y
Maintenance Cartridge MC-10
3
Approximately 2,700 pages with A0 conversion, plain paper, standard mode (photo mode), 12.5% duty per color (by 5 colors)
imagePROGRAF iPF755/iPF750 Service Guide
Rev. 1
Tool
1
Part Number
QY9-0103-000
CK-0541-000
QA2-6161-000
CK-0562-000
CK-0551-020
CK-0336-000
QC1-5547-000
CK-0327-000
Part Number
3630B003AA
0894B001AA
0895B001AA
0896B001AA
3631B001AA
0898B001AA
1320B014AA
imagePROGRAF iPF755/iPF750 Service Guide
Use
For assembling stand and removing the fixed parts
For test print when you confirm printer operation
For unpacking
Use
For pressing down cover switch
For draining ink manually
For draining ink manually
For applying to places specified in the Service
Manual
For applying to places specified in the Service
Manual
For cleaning
For cleaning. To prevent from dirtying hands with
ink.
For locking/unlocking the carriage
1
Remarks
Replace approximately every 2,700 pages
3
