Vacuum
Hose to
Trap
Vacuum
Pump
Power Cord
with
Reverse IEC
Connector
Power cord
to electrical
service
Testing

Turn the CentriVap Concentrator power switch ON.

Close the lid on the CentriVap Concentrator.

Close the lid on the Cold Trap (if equipped)

Press the Run/Stop button on the CentriVap Concentrator.

Once the CentriVap attains speed the vacuum pump should start automatically.

To stop the CentriVap Concentrator press the Run/Stop button.

If the CentriVap Concentrator or Cold Trap fails to perform as expected, consult
the User's Manual for troubleshooting or call Labconco at 1-800-821-5525.
This Quick Start Installation Guide may not provide all the information necessary
for your particular CentriVap Concentrator installation. For further details and
precautions, access to video links and the full user's manual, scan the QR Code
below or click here.
Part Number 1071000, Rev. -, ECO N235 Page 4 of 7
