IARMOR EDGE™
BEFORE INSTALLATION:
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS
ARE PRESENT. READ INSTRUCTIONS CAREFULLY
BEFORE STARTING INSTALLATION. ASSISTANCE IS
RECOMMENDED. THANK YOU FOR CHOOSING OUR
PRODUCT!
*ROCKER PANEL MOUNT
*DRILLING MAYBE REQUIRED
Driver
1#
1#
1#
iArmor
Front
4#
4#
4#
Customer Support: info@iarmorauto.com
®
Fastener Size
Tightening Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
3#
3#
3#
1
PART#: IA-W179
Required
√
6-7
16-18
√
31-32
√
56-58
X
92-94
X
Passenger
2#
2#
2#
Rev. 20220601
