IARMOR EDGE™
BEFORE INSTALLATION
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE
PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. ASSISTANCE IS RECOMMEND-
ED. THANK YOU FOR CHOOSING OUR PRODUCT!
*ROCKER PANEL MOUNT
*DRILLING/TRIMMING NOT REQUIRED
PART LIST
Driver Side Step Bar
iArmor
Front
Driver Front / Rear /
Passenger Center
Mounting Bracket (DFM/
DRM/PCM)
(PFM/PRM/DCM)
Driver Center Mounting
Bracket 1 (DCM1)
(DFM/DRM/PCM)
Customer Support: info@iarmorauto.com
®
Torque Value
Fastener Size
Tightening Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Passenger Front /
Rear / Driver Center
Mounting Bracket
(PFM/PRM/DCM)
(DFM/DRM/PCM)
Passenger Center Mounting
Bracket 1 (PCM1)
(PFM/PRM/DCM)
1
PART#: IA-W171
Required
6-7
X
16-18
√
31-32
√
56-58
X
92-94
X
Passenger Side Step Bar
Rev. 20220502
