Summary of Contents for Enwork Stealth Conference Table
- Page 1 Stealth Base Installation Guide Stealth Conference Table TI0084 Stealth Installation Guide REV a DATE: 07/11/23...
- Page 2 1) TOOLS AND SUPPLIES REQUIRED Mid Base (only for mid Work Surface End Base Base Connection Bracket base application) Mid Base Connection Work Surface Bracket Small Spacer Block (only Bracket (only for mid base Large Spacer Block for mid base application) application) Beam Level...
- Page 3 2) PART AND FASTENERS INCLUDED #10 x 1“ #10 x ½” Self Drilling Truss Head SQ/Phillips LY.MTP PLATE 5/16-18 Flange Nut Screws (SCREW1) Zip-Bolt Connector (only for Biscuit (only for multi- multi-piece tops) piece tops) TI0084 Stealth Installation Guide REV a DATE: 07/11/23...
- Page 4 3) ASSEMBLIES/SUB ASSEMBLIES AND PROCESS Attach brackets to end base using the large spacer blocks, LY.MTPs and 5/16-18 flange nuts. Repeat on other side. Fig 3.1 Attach brackets to beams using large spacer blocks, LY.MTPs and 5/16-18 flange nuts. Repeat on other side. Note: LY.MTPs are installed into the slot as shown be the solid red arrow.
- Page 5 3) ASSEMBLIES/SUB ASSEMBLIES AND PROCESS Attach work surface brackets to beams using #10 self drilling screws. Brackets should be evenly spaced along the beam. Note: Brackets should be flush to the edge of the flange as shown by the solid red arrow. Number of brackets can vary by table size.
- Page 6 3) ASSEMBLIES/SUB ASSEMBLIES AND PROCESS Fasten work surface to base using #10 truss head screws. Fig 3.7 Level table using levelers on end and mid bases. Assembly is complete. Fig 3.8 TI0084 Stealth Installation Guide REV a DATE: 07/11/23...
- Page 7 12900 Christopher Drive Lowell, MI 49331 800.815.7251 www.enwork.com Specifications subject to change without notice.
