Enwork Stealth Conference Table Installation Manual page 5

3) ASSEMBLIES/SUB ASSEMBLIES AND PROCESS
Fig 3.4
Fig 3.5
Fig 3.6
TI0084 Stealth Installation Guide REV a
Attach work surface brackets to beams using #10
self drilling screws.
Brackets should be evenly spaced along the beam.
Note: Brackets should be flush to the edge of the
flange as shown by the solid red arrow.
Number of brackets can vary by table size.
Place and locate work surface on base assembly.
Multi piece tops will require Zip-bolt connectors
and Biscuits. Zip-bolt connectors can be tightened
with a 5mm Allen Wrench.
Note: Only for multi-piece top applications.
DATE: 07/11/23
