NSD ABSOCODER NCW-3DHPNLC Specifications & Instruction Manual page 29

● In the case of using the commercially available cable (JKPEV-S 1.25mm
with a connector
ABSOCODER sensor
ABSOCODER sensor
Connector pin No.
and wire color
Pin Signal
Wire color
No. names
1 SIN＋
Brown
2 SIN－
Red
3
Orange
－COS＋
4
Yellow
－COS－
5 OUT1＋
Green
6 OUT1－
Blue
7
－ －
8
－ －
9
－ －
10
－
－
11 Shield
Shield
12
－
－
Cautions for the connection by the connector
1: The wire No. of JKPEV-S cable is printed on the surface of the white wire.
2: Unused wires of JKPEV-S cable should be severed at both ends.
Please install the connector
by customers
JKPEV-S Cable cross section
Commercially available cable
JKPEV-S cable
Connector pin No. and wire color
Pin Wire No. Wire
No. (pair) color
1
White
1
2
Black
3
White
2
4
Black
5
White
3
6
Black
7 4 White
8 (Not used)
Black
9 White
5
(Not used)
10 Black
11
Shield
12
－ －
22
×5P) and connecting
2
NSD special cable
NSD special cable
Connector pin No.
Signal Pin
names No.
SIN＋ 1
SIN－ 2
3
Orange
－COS＋
4
－COS－
OUT1＋ 5
OUT1－ 6
7
－
8
－
9
－
10
－
Shield 11
12
－
Converter
and wire color
Wire Signal
color names
SIN＋
Brown
SIN－
Red
－COS＋
Yellow
－COS－
OUT1＋
Green
OUT1－
Blue
Violet
－
Gray
－
－ －
－ －
Shield
Shield
－ －
