NSD ABSOCODER NCW-3DHPNLC Specifications & Instruction Manual page 27

Applicable sensor: cylnuc cylinder, vls-12.8pra28, vls-12.8mhp28, irs-51.2p

7-1-1. Connection configure example of the sensor cable

● In the case of using the NSD special cable

ABSOCODER sensor

Extension sensor cable

Converter

With interconnecting cable

Without interconnecting cable
