EVAL-PS-DP-MAIN-M5
Evaluation platform for 600 – 1200 V SiC MOSFETs and IGBTs in TO-247
4pin/3pin packages
Table of contents
measurements. Configuration 3 and Configuration 4 can be used for buck and boost converters, respectively. As
these converters process power continuously. The heatsink and the inductor must fulfill specific voltage, power,
and switching frequency specifications. The maximum current in continuous-mode operation is up to 5 A. This
limitation comes from the board traces and connectors. During continuous operation, cooling should be applied
to the active power components.
Different modes of operation and their configurations
Table 3
Configuration
Switching
(Switch characterization)
Switching
(Switch characterization)
(1) Converter (Buck)
User guide
DUT Parameter
Switch S2 V
DS
Diode S1
I
D
T
C
V
GS
Package
Diode S2 V
DS
Switch S1
I
D
T
C
V
GS
Package
Switch S1 V
DS
Diode S2
F
SW
P
out
V
GS
Package
Limit Simplified technology
< 800 V
< 200 A
< 150°C
-
TO-247
< 800 V
< 200 A
< 150°C
-
TO-247
< 800 V
-
-
-
TO-247
12 Revision 1.0
2025-01-10
