4 Jumper settings for STSPIN948 selection
For selecting dual independent full bridge mMode (Fixed OFF time), follow below jumper settings:
S.No.
1
2
3
4
5
6
UM3482 - Rev 1
Table 1. MODE selection
Jumper Configuration
J6
J7
J8
J11
J12
J13
Jumper settings for STSPIN948 selection
1-2
2-3
1-2
1-2
2-3
1-2
UM3482
Comments
MODE 1 LOW
MODE 2 HIGH
MODE 3 LOW
MODE 1 LOW
MODE 2 HIGH
MODE 3 LOW
