ST X-STM32MP-RBT01 Getting Started page 16

Figure 15.
3V3
R1
1K
SB1 SB2 SB3
0/NM 0/NM 0/NM
GND
U1
1
E0
2
E1
3
E2
4
VSS
M24C32-RMN6TP
R5 R6 R7
22K/NM 22K/NM 22K/NM
GND
GND
Mouting hole_3.2mm drill
Mouting hole_3.2mm drill
X-STM32MP-RBT01 circuit schematics (2 of 10)
3V3
C1
100nF
R2 R3 R4
1K 3.9K 3.9K
8
VCC
7
WC
6
SCL
5
SDA
J1
1
2
3
SHUNT 2.54mm
GND
Jumper EEPROM (WC)
1-2 WRITE_ENABLE
2-3 (DEFAULT) WRITE_DISABLE
J2 J3
1
1
Mouting hole_3.2mm drill
J4 J5
1 1
Mouting hole_3.2mm drill
EEPROM_ID_SC
EEPROM_ID_SD
2mm
17mm
Camera Slot
