ST X-STM32MP-RBT01 Getting Started page 25

9 Bill of materials
Item
1 12
2 3
3 1
4 2
5 3
6 4
7 10
8 4
9 4
10 2
11 1
12 1
13 1
14 2
15 1
16 4
UM3482 - Rev 1
Table 12.
Q.ty Ref. Part/value
C1, C2, C3, C4,
C5, C34, C35,
100nF
C37, C39, C40,
C41, C43
C6, C11, C23 0.1 µF
C7 330uF 80V
C9, C21 1uF
C10, C22, C36 220nF
C12, C13, C24,
470nF
C25
C14, C26, C45,
C46, C47, C48,
1nF
C49, C50, C51,
C52
C15, C16, C27,
10nF
C28
C19, C20, C31,
100pF
C32
C33, C38 10uF
C42 4.7uF
Header
CN2
20X2_female
MORSV-508-2P
CN3
_screw
MORSV-508-4P
CN4, CN5
_screw
1.5KE62A,
D1
DO-201AA
D10, D12, D13,
LED GREEN
D14
X-STM32MP-RBT01 bill of materials
Description
CAP CER
0.1UF 16V X7R
0603
CAP CER
0.1UF 50V X7R
0603
Aluminium
Electrolytic
Capacitors -
SMD 80VDC
330uF 20%
SMD
CAP CER 1UF
50V X7R 0603
CAP CER
0.22UF 50V
X7R 0603, CAP
CER 0.22UF
16V X7R 0603
CAP CER
0.47UF 50V
X7R 0805
CAP CER
1000PF 50V
X7R 0603
CAP CER
10000PF 50V
X7R 0603
CAP CER
100PF 50V X7R
0603
CAP CER 10UF
16V X5R 0603
CAP CER
4.7UF 16V X5R
0603
CONN RCPT
40POS 0.1 TIN
PCB
TERM BLOCK
HDR 2POS
VERT 5.08MM
TERM BLOCK
HDR 4POS
VERT 5.08MM
TVS D5.4X7.5
300V 1500W
UNIDIR
LED GREEN
CLEAR 0603
SMD
Bill of materials
Manufacturer Order code
KEMET C0603C104K4RACTU
YAGEO AC0603KRX7R9BB104
Panasonic EEEFK1K331AM
Würth
885012206126
Elektronik
YAGEO, Walsin
AC0603KRX7R9BB224,
Technology
0603B224K160CT
Corporation
Würth
885012207102
Elektronik
Würth
885012206083
Elektronik
Würth
885012206089
Elektronik
Würth
885012206077
Elektronik
Murata
ZRB18AR61C106ME01L
Electronics
Murata
GRM188R61C475ME11D
Electronics
Samtec Inc. SSQ-120-03-T-D
Würth
691311500002
Elektronik
Würth
691311500004
Elektronik
ST 1.5KE62A
Würth
150060GS75000
Elektronik
UM3482
page 25/36
