Summary of Contents for Jaypro Sports BOMBER PRO
- Page 1 -- BBGS-18 -- (BOMBER PRO BATTING CAGE) Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com 3/23/23 Page 1 of 16...
- Page 2 4. USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS. 5. ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. LIST OF RECOMMENDED TOOLS & SUPPLIES ITEM DESCRIPTION POWER DRILL WITH 3/16”...
- Page 3 BBGS-18 QUICK REFERENCE ( SEE EXPLODED VIEWS OF DIFFERENT SECTIONS FOR HARDWARE CALLOUTS ) Note: It is critical the area you select be as flat as possible, as there are steps during assembly that call for alignment of holes using a level. Note: Assembly requires two people.
- Page 4 Assemble Framework: 1. Connect curved pipe (15) to pipe 98-3/4” long (2) w/ lock nut & hex bolt & connect curved pipe (15) to pipe 91” long (3) w/ lock nut & hex bolt. [BBGS-18] FIGURE #1 3/23/23 Page 4 of 16...
- Page 5 2. Connect curved pipe (15) to rear welded section (5) w/ lock nut & hex bolt. Note: Slide on collar (29) to pipe (3) & collar (30) to pipe (2). [BBGS-18] FIGURE #2 3/23/23 Page 5 of 16...
- Page 6 3. Assemble pipes (2), (3), (7) & plate (13) w/ 1/2" hardware as shown. Note: DO NOT OVER TIGHTEN. [BBGS-18] FIGURE #3 3/23/23 Page 6 of 16...
- Page 7 4. Assemble wheel (37) w/ hardware as shown. [BBGS-18] FIGURE #4 5. Assemble pipes (10) & (10) to collars (29) & (30), tighten all set screws w/ Allen wrench provided. [BBGS-18] FIGURE #5 3/23/23 Page 7 of 16...
- Page 8 6. Assemble all parts as shown. Note: it is important to use the washers as shown to prevent moving parts (12) from binding. Note: Do not over tighten hardware. [BBGS-18] FIGURE #6 3/23/23 Page 8 of 16...
- Page 9 7. Assemble curved pipe (15) to 78” long pipe (16). 8. Assemble curved pipe (15) to 70” long (12). 9. Assemble curved pipe (15) to L-shape pipe (7). [BBGS-18] FIGURE #7 3/23/23 Page 9 of 16...
- Page 10 10. Assemble all parts as shown. [BBGS-18] FIGURE #8 3/23/23 Page 10 of 16...
- Page 11 [BBGS-18] FIGURE #8.1 3/23/23 Page 11 of 16...
- Page 12 Assemble struts: (BBLS123) After the frame is fully assembled check all hardware to make sure it is tightened and all joints are secured. Raise the upper frame arches into position, using the strut pipes, and check for alignment. (See setup instructions) Attach padding: 1.
- Page 13 Attach net: Description: The outer perimeter of the net is to be fully laced to both the front arch and the top member of the lower frame. (See detail showing how to lace if unfamiliar with lacing). The net will be suspended off the center two arches, by about 6”. 1.
- Page 14 Attach skirt: 1. Fully raise the upper portion of the cage. 2. Attach the vinyl skirt to the top and bottom pipes of the lower frame, using the zip ties or black cord rope cut at 18” long. 3. For best results, start at the center and work out to the front corners. 3/23/23 Page 14 of 16...
-
Page 15: Set-Up And Transport
SET-UP AND TRANSPORT Raising and Lowering the Upper Cage: NOTE: At least two people are required for the following steps. Caution: Keep body parts clear of pinch points between pipes and fittings. 1. Two struts are required to raise and support each arch. The raising of each arch must be done in tandem, with equal pressure and extension. -
Page 16: Maintenance Instructions
TRANSPORTING CAGE: • Cage can be transported by going forward or backward. Transporting the cage should be done with 2 or 3 people. Note: Cage should only be transported in the fully folded position. Never move cage when fully raised. 1.
