- Page 1 -- BBFP-40SM -- -- SBFP-40SM -- (40’ PROFESSIONAL / SOFTBALL FOUL POLE) Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Page 1 of 9...
- Page 2 40’ Professional / Soft Ball Foul Pole, BBFP-40SM / SBFP-40SM QUANTITY IS FOR ONE COMPLETE FOUL POLE ITEM IMAGE DESCRIPTION TOP UPRIGHT POLE P/N: BBFP-40TU BOTTOM UPRIGHT POLE P/N: BBFP-40SM-BU MIDDLE PANEL P/N: BBPS-B 3/8” FLAT WASHER P/N: HW2047 3/8”-16 NYLON LOCK NUT P/N: HN265 3/8”-16 x 1”...
- Page 3 ITEM IMAGE DESCRIPTION 24” LONG L-HOOK P/N: SR5401 LEVELING PLATE P/N: SR5402 1”-8” HEX NUT P/N: HN274 1” FLAT WASHER P/N: HW5052 TOP CAP FOR 6-5/8" OD P/N: EC0070 ITEM IMAGE DESCRIPTION • Unpack all parts and check against parts list to ensure that all have been included. •...
-
Page 4: Tools/Materials Required
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS. 3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. 4) CONCRETE SHOULD BE A MINIMUM 4000-PSI MIX. ASSEMBLY INSTRUCTIONS TOOLS / MATERIALS REQUIRED: (6) 3/4”... - Page 5 FIGURE: 1 REBAR BASKET (6) ¾” x 66” REBAR (BY OTHERS) 1”-8 HEX NUTS w/ WASHERS Once foundation finished curing, backoff the nuts and place a washer. FIGURE: 2 Note: These are suggested dimensions for average soil conditions, consult local building codes. *For Areas Subject To Higher Wind Loads Footing Dimensions May Need To Be Adjusted.
- Page 6 3. Rotate the upright as needed to align the panel mounting holes per the figure 1 (note mounting holes for panels). 4. Secure the mounting plate with 1”-8 nuts & washers. 1”-8 HEX NUTS w/ WASHERS BOTTOM POLE P/N: BBFP-40SM-BU FIGURE: 3 Page 6 of 9...
- Page 7 3. Line up the holes for the wing panels in both the top and bottom poles. TOP CAP P/N: EC0070 TOP UPRIGHT POLE P/N: BBFP-40TU FIGURE: 4 TOP UPRIGHT POLE P/N: BBFP-40TU BOTTOM UPRIGHT POLE P/N: BBFP-40SM-BU (apply light layer of grease if needed) Page 7 of 9...
- Page 8 Wing Panels: 1. Attach all the wing panels per figure 5. Orient the panels so the front side is facing the field. (Note image shown is from the back side of panels.) 7/16”-14 x 8” HEX BOLT P/N: HS5386 3/8”-16 x 1” HEX BOLT P/N: HS286 3/8”...
- Page 9 2. Rotate the pole to position the panels perpendicular to the foul line, as shown in figure 1. If needed, rotate the top pole so the wing panels attaching to the bottom pole are in line with the top. Install the bottom two panels as shown in figure 5. 3.
