- Page 1 PVB S AYPRO ERIES LASSIC TEEL OLLEGIATE YSTEM Installation and Operating Instructions Applicable Part Numbers/Models: PVB-3000: Classic Steel Collegiate Net system JSL-Inst042 www.jayprosports.com...
-
Page 2: Table Of Contents
PVB Series Classic Steel Collegiate Net System Instructions Table of Contents Safety ........................ 2 Specifications ....................2 Introduction ..................... 2 Required Tools ....................3 Included Hardware & Components ............4 5.1 System Components................4 5.2 Hardware ....................5 Assembly ......................6 Maintenance .................... -
Page 3: Safety
If you require additional information or support to install or operate your volleyball system, please contact the Jaypro Sports customer support team, Monday through Friday, 8:30AM to 5:00 PM (EST), at 1-800-243-0533. NCAA and NFHS rules require that the upright standards must be installed at least 3’3”... -
Page 4: Required Tools
Figure 3-1: Correct Ground Sleeve Dimensions Required Tools Before continuing, please verify that you have the following tools required to complete the installation and setup of your PVB Series Collegiate Net System. Adjustable wrench ▪ Hex keys – 3/16”, 5/16”... -
Page 5: Included Hardware & Components
Before continuing, please open all packages to verify that you have all the required hardware for installation and setup. If any of the following items are missing, contact the Jaypro Sports customer support team, Monday through Friday, 8:30AM to 5:00 PM (EST), at 1-800-243-0533. -
Page 6: Hardware
PVB Series Classic Steel Collegiate Net System Instructions Figure 5-4: Antennae and Net Tapes (VBA-80, 1 pair) 5.2 Hardware Figure 5-5: Net extension cord 31 inches (PVBN6R2, 2X) Figure 5-6: Socket Cap Screw (HS5082, 1X) Figure 5-8: Centering Strap (PVB604, 1X) -
Page 7: Assembly
PVB Series Classic Steel Collegiate Net System Instructions Assembly WARNING: Uprights are heavy. Do not attempt to lift or install without assistance. 1. Install each upright into the ground sleeves. 2. Follow instructions included with winch to set the winch clamp to the correct upright diameter (3”). - Page 8 PVB Series Classic Steel Collegiate Net System Instructions 5. Install 31 inch net extension cord and the centering strap assembly to the upright without the winch. (Figure 6-2). Figure 6-2: Install net extension cord to anchor side. - 7 of 9- JSL-Inst042 www.jayprosports.com...
- Page 9 PVB Series Classic Steel Collegiate Net System Instructions 6. Attach one end of net to 31 inch Extension Cord with the Carabiner provided, then attach other end of the extension cord to the winch strap (Figure 6-3). Figure 6-3 : Attach net to straps.
-
Page 10: Maintenance
12. Install pads around each upright. Maintenance Your PVB Series Classic Steel Collegiate Net System is designed to provide years of play; however, it is recommended that the components be inspected at least once every season, for signs of excessive wear. Key areas to inspect include (but are not limited to): Strap webbing ▪...
