--- BBC-QS70 ---
(Quick Set-Up Batting Tunnel)
Installation Instructions
OPTIONAL WALL MOUNTING KIT
OPTIONAL WALL HOISTING KIT
OPTIONAL NET STORAGE CART
MODEL #: BBC-WLKT
MODEL #: BBC-QSKIT1
MODEL #: TENINJA-CART
Call Jaypro Sports Equipment at 1-800-243-0533 during
regular business hours for technical support.
www.jaypro.com
Rev - D
Page 1 of 9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jaypro Sports BBC-QS70
Summary of Contents for Jaypro Sports BBC-QS70
- Page 1 OPTIONAL WALL MOUNTING KIT OPTIONAL WALL HOISTING KIT OPTIONAL NET STORAGE CART MODEL #: BBC-WLKT MODEL #: BBC-QSKIT1 MODEL #: TENINJA-CART Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Rev - D Page 1 of 9...
-
Page 2: Important Notice
PLACED ON THE WALL OR END STRUCTURE. PRODUCT DESCRIPTION: The BBC-QS70, quick set-up batting tunnel kit is designed to attach to the walls of a gym. The distance between walls should not exceed 120 ft and must be a minimum of 85 ft. During set-up the net easily attaches to three (3) pre-installed polyester lines coming off of each wall. -
Page 3: Tools Required
• Inspect all parts for damage. Report any damages to the trucking company. ITEM DESCRIPTION BBC-QS70 70’ x 14’ x 14’ BBC NET (P/N: BBC-701414) 5/16” x 300 FT LONG BLACK BRAIDED ROPE PULLEY BLOCK w/ CAM CLEAT (P/N: HM6568A) - Page 4 1) Mark the location of the cable anchor as shown in the diagram below. Anchor Point Locations on Building Wall (Both Ends) Note: The height of the cables should be set at about 9” below the overall height of the net. This will place about 12”...
- Page 5 2) Install the wall anchors on both sides of the gym, as shown below. Follow the appropriate figure for your building type. Note: if optional wall mounting kit (BBC-WLKT) is purchased; please see installation instructions that come with it. Figure 1: Standard Building Attachment - For Metal Structure and Wood Blocking Figure 2: Standard Building Attachment - For Solid Concrete Walls (Double Expansion Shield Anchors Not Provided) Figure 3: Optional Wall Mounting Kit –...
- Page 6 3) Make up and install the three fixed end lines. Based on the desired distance off the wall, cut three equal lengths of 5/16” black braided rope and tie two snap hooks to each end. Attach the three lines to the wall anchors. Figure 4: Fixed End Support Lines (Line Length Base on Desired Distance off the Wall) 4) Make up and install the three hoisting lines.
- Page 7 5) Make up the six leads on the end of the net as shown in Figure 6. Note: Top cords should be anchored to the net in all six locations. Do not undo knots securing the cords to the net body. Figure 6: Assemble Net Leads (6 Places on Netting) 6) Attach one end of the net to the fixed end lines.
- Page 8 7) Make any necessary adjustments. 8) Install the Six, 6” wide steel cleats beneath each of the six lines, see Figure 8 & 9. It is recommended that the cleats be installed at a height of at least 7 ft above the floor. Figure 8: Standard Building Attachment - For Metal Structure and Wood Blocking Figure 9: Standard Building Attachment on Fixed End - For Solid Concrete Walls (Double Expansion Shield Not Provided)
- Page 9 OPTIONAL KITS AND HARDWARE: MODEL #: BBC-WLKT WALL MOUNTING KIT: (QTY: 6) Wood stringers and mounting plates for attaching to CMU block and concrete walls. MODEL #: TENINJA-CART: Net storage cart. MODEL #: BBC-QSKIT1 Supplemental Wall Hoisting Kit To be used if the anchor lines are too short to access from the floor, or to provide added tension if the hoist end is bottomed out.
