  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support Brushless DC motor Model: JZ48V1800W We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 3: Safety Precautions

    Safety precautions 1.1Safety advisory warning Please read carefully before operation. Be sure to read all safety warnings and all instructions before operating the motor. Failure to comply with warnings and instructions may result in electric shock, fire or serious injury. If you encounter problems, please communicate with customer service in time to solve, your satisfaction is our service purpose.
  • Page 4 2) It is recommended to use lead-acid batteries. Lithium batteries can also work (note that the battery voltage and battery power match the kit power). The recommended battery capacity is 12AH-20AH. The battery voltage needs to be consistent with the motor kit voltage, allowing an over voltage range of +10%. The positive and negative terminals of the power supply must be connected correctly (the positive terminal is connected to the thick line of the controller in red, and the negative terminal is connected to the thick line of the controller in black).

  • Page 5: Technical Info

    TECHNICAL INFO PERFORMANCE PARAMETERS OF JZ48V1800W MOTOR Parameter Numerical value Rated voltage/V (DC) Maximum wattage/W 1800 Rated speed/rpm 4500 Rated torque/N.m Rated current/A No-load speed/rpm 5600±10% Motor efficiency ≥85% Sprocket number T8F-9T and T8F-11T M8 Left-hand tighten thread *1.25*12mm (There is thread glue at the thread, and the disassembly Screw thread needs to be heated at 80℃...

  • Page 6: Configuration List

    PERFORMANCE PARAMETERS OF ZWK4833 CONTROLLER Parameter Numerical value Rated voltage/V (DC) Maximum wattage/W 1800 Rated current/A Brake Low level brake Under voltage/V Operating temperature/℃ -25~60 Controller enclosure size/mm 212*87*49(error±2mm) Controller mounting hole/mm 199*44*∅6(error±2mm) Weight/kg 0.63 CONFIGURATION LIST ② ZWK4833 SHSS01 ③...
  • Page 7 ④ Electronic throttle pedal ⑤ Lead-acid charger ⑥ Handlebar X1 PCS X1 PCS X1 SET ⑦ Multi-functional British ⑧ Extended high standard European ⑨ Hardware kit temperature line standard adapter plug X1 SET X1 SET X1 SET Table 1 Product configuration table Product number Product configuration ZLWSDJTJ18007TVWHV9...
  • Page 8 Overall dimensions and mounting dimensions The dimensions and mounting dimensions of the motor are shown in Figure 1. Figure 1 Motor dimensions and mounting dimensions Install 1. Motor The A-phase line of the motor lead out main line is blue, the B-phase line is green, and the C-phase line is yellow;...
  • Page 9 2. Controller There are two types of controllers. The functions of each plug-in are shown in Figure 3 below. Figure 3 Controller - 8 -...
  • Page 10 Controller voltage: DC48-54V 1. Red 48V+ 2. Black 48V- The positive and negative values cannot be connected incorrectly, otherwise the controller will burn out. There will be a slight spark when connected, which is a normal start up phenomenon. Figure 4 shows the controller cable connections. 3.
  • Page 11 3.2 Pedal/accelerator Pedal/accelerator wire (twist throttle) 1. Red: +4.3V 2. Black: Ground wire 3. Gray: Signal line The pedal/accelerator wiring is shown in Figure 6. Figure 6 The pedal/accelerator wiring 3.3 Charger Charging port: (Charge input voltageAC220) Red: InputDC48V Black:Input- The positive and negative electrodes must be connected correctly.
  • Page 12 3.4 High-temperature wire Controller integrated plug-in and cable connection. Figure 8 shows the high-temperature cable connection. Figure 8 Wiring high-temperature cables 4. Other accessories installation (purchase by oneself) 4.1. Three-speed switch Three speed switch: default speed 2, short circuit of blue and black lines is 3 speed, short circuit of yellow and black lines is 1 speed).
  • Page 13 4.2 Reverse Reverse: Switch brown and black, reverse speed is 100%. There are the following types of reverse cables. Figure 10 shows the reverse cables. Figure 10 Reverse cable connection 1. Two-pin switch controls forward and 2. Handle with reverse function backward 4.3 Brake Brake: Connect the brake to realize the brake power off function.
  • Page 14 4.4 Electric door lock Electric door lock: 1. Red: p+ Orange: VCC The electric door lock must be kept normally open, or the red and orange lines must be connected by a short circuit. Electric door lock wiring has the following types, electric door lock wiring is shown in Figure 12.

  • Page 15: Correct Disposal

    COMMON PROBLEMS AND REMEDIES Phenomenon: The electronic lock must be opened, When the electronic lock is opened, the throttle is turned and the motor does not work Reason: Battery The battery is too low and does not reach the required operating voltage Solution: 1.
  • Page 16 may cause undesired operation. WARNING: Changes or modifications to this product not expressly approved by the party.responsible for compliance could void the user's authority to operate the product. Note: This product has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules, These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 17 Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN. Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 YH CONSULTING LIMITED. C/O YH Consulting Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4AX E-CrossStu GmbH...
  • Page 18 Technical Support and E-Warranty Certificate www.vevor.com/support...
