Summary of Contents for Puretec Hybrid G Series

  • Page 1 Hybrid G/R Hybrid G / R Filtration & UV All-in-One Unit User Guide R A I N W A T E R...
  • Page 2: Table Of Contents

    DO NOT OVERTIGHTEN. WMTS103 Certificate No. WM 74593 DO NOT USE Pro-Switch Pty Ltd LIQUID SEALANTS. SURGE PROTECTION REQUIRED / NO EXTENSION CORDS. SURGE PROTECTION REQUIRED / NO EXTENSION CORDS. Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 3: Puretec Customer Service

    UV system is dependent on the clarity of water present. If you are unsure of the clarity of your water Puretec can arrange a UVT test to verify that no further filtration is required before the UV. Contact Puretec on 1300 140 140 (AU) or 0800 130 140 (NZ) for further information on this.
  • Page 4: Preparing Your System

    Preparing the system Preparing Your System Puretec systems are designed to run economically for many years, dependent on the initial installation and periodical maintenance. Please read all instructions carefully as failures caused by incorrect installation or operation are not covered by warranty.
  • Page 5: Positioning Your System

    (non-replaceable) to protect the circuit. The fuse is not a lightning arrester and may not protect the Radfire if lightning or a very powerful surge hits the unit. A suitable surge protection device has been provided with this product. Puretec recommends the use of a surge protector (the one supplied or otherwise) or warranty may be voided.
  • Page 6: Installation Requirements

    Hybrid R models are intended for indoor installation (must be protected from weather, frost, water and have adequate ventilation). • All Puretec Hybrid models should be protected from harsh environments where overexposure to salt or aggressive chemicals can occur. •...
  • Page 7 • If bacteria has been present prior to the installation of this system, we recommend flushing the pipelines with Puretec TankSafe. • Warning: The UV chamber should only be connected to metal pipe and/or fittings for at least 1 metre after the outlet. Never connect plastic pipes or fittings directly to the UV chamber.
  • Page 8: Initial Installation Procedure

    Phone: Date Installed: Initial Installation Procedure The Puretec Hybrid Series has 1" [25mm] plumbing connections. Before attempting installation check the unit to ensure the quartz sleeve is intact within the Radfire UV Unit. Locate a suitable position for the Hybrid system remembering to allow 120mm under units with 20"...
  • Page 9: Installation Procedure

    Installation Procedure HYBRID G13 MODEL HYBRID G12 MODEL 700mm clearance 700mm clearance allow min. 120mm clearance from the ground HYBRID R2 / R4 MODEL HYBRID R1 / R3 MODEL 700mm clearance 700mm clearance allow min. 120mm clearance from the ground HYBRID SERIES | Filtration &...
  • Page 10 Drill the holes and install the anchors (fixing anchors not included). Position the Hybrid. Hybrid G: Position on the wall and tighten the fixings to hold the system securely to the wall. 10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 11 valve Installation Procedure Hybrid R: Position on the wall. Insert and tighten the fixings to hold the system securely to the wall. This unit can be installed from left to right or right to left depending on the water supplies point of entry.
  • Page 12: Operation

    AC 240V | 50Hz Lamp Power: 35W~95W Lamp Current: 0.8A~0.9A Ambient Temperature: 4~40°C Lamp Rated Life: 365 days Caution: Ground the ballast casing to avoid possible high voltage shock hazard 12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 13: Lamp Ballast Diagram

    UV Chamber Diagram Fig. 5 UV Chamber Diagram Lamp Power Connector Grounding Wire & Safety Cap Aluminium Nut O-Ring UV Lamp Quartz Sleeve Mounting Flange Water Outlet Water Inlet Spring O-Ring Aluminium Nut HYBRID SERIES | Filtration & Ultraviolet Disinfection All-in-One Unit...
  • Page 14: Replacement Parts Guide

    To maintain a high quality of purified water, the cartridges will need changing periodically (dependent on water quality and usage). You can obtain replacement cartridges from your local Puretec dealer. To maintain performance, warranty and Australian Standards use genuine Puretec replacements.
  • Page 15: Cartridge Replacement Procedure

    Replacement Procedure Cartridge Replacement Procedure To change the filter cartridges please adhere to the following procedure: Turn water supply off and relieve pressure by opening a downstream tap or pressing the red pressure relief button on the housings. Unscrew the filter bowls. If the bowl is difficult to undo, the spanner provided may be used to make it easier.
  • Page 16: Lamp Replacement Procedure

    Note: For initial use, wait 3-5 minutes to allow water to pass through the whole unit. Turn on a downstream tap to let water flow through the unit for 2-3 minutes to release air and impurities from system. O Ring 16 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 17 Replacement Procedure Press and hold the silver button for 15 seconds, when an audible "beep" will sound, indicating that the lamp life timer has been reset for a further 12 months. If you have the Hybrid G model, close and lock the lid. Note: Your cabinet comes with a key for your convenience.
  • Page 18: Quartz Sleeve Maintenance/Replacement Procedure

    Aluminium Nut is removed, hold the bottom of the Replacing UV Lamp Quartz Sleeve and remove the bottom O-Ring. O Ring cont. over page. 18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 19 Maintenance Procedure valve Cleaning Quartz Sleeve placing UV Lamp Cleaning Quartz Sleeve Cleaning Quartz Sleeve cont. Slide the Quartz Sleeve through and out of the top of the chamber. Clean the Quartz Sleeve with an alcohol based valve mins cleaner if necessary. Replacing UV Lamp Fig.
  • Page 20 12. If you have a Hybrid G model, close and lock the lid. Your cabinet comes with a key for your convenience. Please store it safely. Note: Lost or misplaced keys are not covered by warranty. 20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 21: Troubleshooting Guide

    Troubleshooting Guide SYMPTOMS POSSIBLE CAUSE POSSIBLE SOLUTION No power. • Ballast and/or breaker tripped. • Reset ballast and/or breaker. • Ballast damaged. • Replace ballast. Ballast or breaker • Connection between lamp and • Clean and dry lamp pins repeatedly trips. lamp plug is wet.
  • Page 22 Display flashing. • Power interruption. • Reset ballast. Error Code ‘A3’ on • Ballast countdown has • Replace lamp. ballast. reached 0, lamp life expired. 22 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
  • Page 23: Warranty

    Warranty/Australia This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road, Lonsdale SA 5160, telephone no. 1300 140 140 and email at sales@puretec.com.au.
  • Page 24 JUN2023...
