Brinkmann–Horizontal End Suction Pumps Series SBA1600...2000, SBG1400…1700 and SBF1350...1850 Contents 9 Trouble shooter’s guide ........7 Indication to the manual ........2 Description of product ........2 10 Spare part ............8 Safety instructions ..........3 11 Repair Instructions ........... 9 Transport and storage ........
It is imperative that signs affixed to the machine, e.g.: *) Dimensions for SBF1350 • arrow indicating the direction of rotation **) Dimensions for SBA2000 and SBG1700 • symbols indicating fluid connections be observed and kept legible. Unauthorized alterations and production...
Page 5
Electric wiring Wiring diagram e.g. Star connection up to 5.5 kW 3 x 400 V, 50 Hz All service work must be carried out by quali- resp. 380-415 V, 50 Hz fied service personnel. Pump must be discon- nected from the power source and all rotating parts must stand still.
6 Start up / Shut down Start up ATTENTION Switch off at the mains. After connection the electrical wires, close the terminal box. Briefly start the motor (max. 30 sec.) and check the rotation according to the arrow on the top of the motor. If the direction is incorrect change over two of the power leads.
8 Servicing and Maintenance Pumps with double mechanical seal (-GD) Pumps with double mechanical seal (-GD) are ATTENTION identified by the letters GLRD stamped in on the motor side of the pump foot and must include an oil The surface of the motor must be kept free of dirt. receiver with a capacity of 1.1 litres.
10 Spare part 10.1 Spare part list for Brinkmann Horizontal SBA1600...2000, SBG1400…1700 and End-Suction Pumps Series SBF1350...1850 Item Description Item Description Stator with terminal board 28 Sealing ring DIN 7603 29 O-ring Motor flange 30 Shaft seal End shield 31 Compensation disk 4.1 Terminal box frame 50 Pump body 4.2 Terminal box cover...
10.2 Indications to the spare part order tionary axial face seal unit (24a) into the pump body (50) and pump foot (12). Slide the rotating Spare parts are available from the supplier. axial face seal unit (24b-24e) onto quick shaft Standard commercially available parts are to be (91) and fix in position using shim ring (22) and purchased in accordance with the model type.
11.2 Dismantling the insert shaft (12 kW and higher) Use a torque screwdriver to tighten each screw first with 2 Nm then with 7 Nm and finally with 12 Nm (in a clockwise direction again). 12) Mount the pump foot and the pump body. The remainder of the reassembly process is to be completed in the opposite order of the prior de- scribed dismantling process.
Brinkmann Pumpen, K. H. Brinkmann GmbH & Co. KG Friedrichstraße 2 D-58791 Werdohl Germany This declaration of conformity is issued under the sole responsibility of Brinkmann Pumps and belongs to the following product. Product name Horizontal End-Suction Pumps SBA1600…2000, SBG1400…1700, SBF1350…1850...
Page 12
13.2 EC declaration of conformity DEUTSCH / ENGLISH /FRANÇAIS / ESPAÑOL EG-Konformitätserklärung EC declaration of conformity / Déclaration de conformité CE / Declaración de conformidad CE Hersteller / Manufacturer / Constructeur / Fabricante Brinkmann Pumpen, K. H. Brinkmann GmbH & Co. KG Friedrichstraße 2, D-58791 Werdohl Produktbezeichnung / Product name / Désignation du produit / Designación del producto Blockpumpen / Horizontal End-Suction Pumps / Pompes horizontales monobloc / Bombas horizontales monobloc...
