P5...L120
Model: M04; M04s; M11
Assembly and Operating Instructions
en
Roller shutter and sun protection drives with
mechanical limit switch
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Related Manuals for Becker P5 L120 Series
Summary of Contents for Becker P5 L120 Series
- Page 1 Roller shutter and sun protection drives with mechanical limit switch Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany www.becker-antriebe.com...
-
Page 2: Table Of Contents
Table of contents General .................................... 3 Warranty ..................................... 3 Safety instructions ................................ 4 Instructions for the user.............................. 4 Instructions for installation and commissioning........................ 4 Intended use .................................. 6 Assembling and disassembling the plug-in connecting cable.................... 6 Assembling the plug-in connecting cable .......................... 6 Disassembling the plug-in connecting cable for tubular drives dia. -
Page 3: General
General These tubular drives are high-quality products with the following features: • For use with roller shutters • For use with sunblinds • Easy limit switch setting on the drive • Compatible with all of the drive manufacturer's control units for roller shutters and sunblinds •... -
Page 4: Safety Instructions
Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. Instructions for the user General information • All work, including maintenance and cleaning, on electrical installations as well as other system parts must always be performed by authorised specialists, in particular qualified electricians. - Page 5 • Moving parts of drives must be installed at a height of over 2.5 m above floor level or any other surface from which access to the drive is gained. • To ensure safe operation of the system after commissioning, the limit positions must be correctly set/ programmed in.
-
Page 6: Intended Use
Intended use The type of tubular drive described in these instructions is intended solely for the operation of roller shutters and sun protection systems. We recommend using drives with more than 17 rpm only in sun protection systems (screens). When mounting connection parts on the drive PXX/XX dia. 35 mm, only use screws EJOT Delta PT 40x12 WN 5454 Torx (9900 000 545 4). -
Page 7: Disassembling The Plug-In Connecting Cable For Tubular Drives Dia. 35
Disassembling the plug-in connecting cable for tubular drives dia. 35. Caution Prior to disassembly, the power supply to the connecting cable must be disconnected. On drives with a diameter Ø35, insert a suitable flathead screwdriver between the locating lug and the snap-in pin, so that the snap-in pin releases the locating lug from the plug. -
Page 8: Disassembling The Plug-In Connecting Cable For Tubular Drives Dia. 45 And Dia. 58
Disassembling the plug-in connecting cable for tubular drives dia. 45 and dia. 58 Caution Prior to disassembly, the power supply to the connecting cable must be disconnected. On drives with a diameter Ø45 or Ø58, insert a suitable flathead screwdriver right into the recess of the locating latch, so that the latch releases the locating lug from the plug. -
Page 9: Undoing The Mounting Pin
Attention When using anti-lifting devices, closed brackets must be fitted. The tubular drive presses the closed curtain down to make it difficult for people to reach under it or raise it. Only use curtains made of sufficiently strong material, such as aluminium, steel or wood. To prevent damage to the curtain it must run in guide tracks from top to bottom. -
Page 10: Fixing The Drive Adapter To The Barrel Dia. 35 And Dia. 45 And Dia. 58
Fixing the drive adapter to the barrel dia. 35 and dia. 45 and dia. 58 Size of drive Diameter of barrel Torque Fastening screws [mm] [mm] max. [Nm] for drive adapter (4 pc.) dia. 35 40 mm plastic drive adapter Self-tapping screw dia. - Page 11 Mount the assembled unit comprising barrel, tubular drive and idler on the box and secure the drive with a split or spring pin ac- cording to the type of wall bracket fixing. The drive can be operated either with the switch (Item no. 4901 001 158 0) or the op- erator control provided.
-
Page 12: Setting The Limit Positions
Setting the limit positions Upper limit position Lower limit position Lower limit position Upper limit position Setting the lower limit position 1. Before the shading solution is fixed to the barrel, let the drive run DOWN until it switches off automatically. 2. -
Page 13: Information For The Electrician
Information for the electrician The tubular drives with mechanical limit switching must not be connected in parallel. The drive manufacturer offers a range of suit- able controls for the simultaneous control of several drives. Use external conductor L1 to control the up and down direction. Other devices or consumers (lamps, relays, etc.) must not be dir- ectly connected to the drive connecting cables. -
Page 14: Technical Data Dia. 45
Technical data dia. 45 Model R8-M04 R12-M04 R20-M04 R12-M11 R20-M11 Type R8/17C M R12/17C M R20/17C M Rated torque [Nm] Output speed [rpm] Limit switch range 38 revolutions Supply voltage 230 V AC / 50 Hz Connected load [W] Rated current consumption [A] 0.45 0.75 Mode... -
Page 15: What To Do If
Model L70-M04 L80-M04 L80-M04 L120-M04 Type L70/17C M L80/11C M L80/17C M* L120/11C M Rated torque [Nm] Output speed [rpm] Limit switch range 36 revolutions Supply voltage 230 V AC / 50 Hz Connected load [W] Rated current consumption [A] 1.90 1.40 2.10 1.90 Operating mode S2 4 min Degree of protection IP 44 Min. -
Page 16: Sample Wiring Diagrams
Sample wiring diagrams Control via a single switch/button Central, group and individual control using Centronic UnitControl UC42 Central Control unit Mains 230 V / 50 Hz Central cable 230 V / 50 Hz (connection to further control units) Group 230 V / 50 Hz Individual Individual 230 V / 50 Hz... -
Page 17: Declaration Of Conformity
Declaration of conformity... - Page 20 2010 300 332 0g 11/08/2015 ...
