K. Indicator Light—This light indicates the laser status. When the laser tube is receiving current during normal
operation, the light shows a green color. In standby mode, it switches to yellow, and in case of a fault, it turns red.
L. Warnings—This notice supplements the Safety Information chapter of this manual. Read it carefully before
using the machine.
M. Power and Inputs—This panel includes the machine's power switches as well as the ports for its USB, computer,
and internet connections.
N. Right Access Door—This door provides access to the mainboard, motor drivers, and power supplies.
O. Front Access Door— This door provides access to the area below the workbed for easy cleanup.
P. Main Power Switch—This switch controls the main power supply to the machine.
Q. Power Sockets—These sockets connect to your main power supply, ground the machine, and provide additional
sockets for your water pump and air assist if needed. It is recommended, however, to use a separate plug on a
different fuse for these devices.
R. Feet—These feet can be rotated down to help anchor the machine in place.
S. Caster Wheels—The front wheels include locks to hold the engraver in place.

Rear View

A. Top Rear Access Door—This door opens to the laser bay, holding the laser tube and its connections.
B. Laser Tube—This long glass tube is filled with helium, nitrogen, and CO₂ gas and water cooled to safely produce
your engraving laser. Its connection to the laser power supply is extremely high voltage and extremely dangerous.
C. Lower Left Rear Access Door—This door provides access to the same area as the right access door.
D. Bottom Rear Access Door—This door provides access to the air pump for easier maintenance.
E. Exhaust Fan Port—Use this port to connect your exhaust fan (not included).
F. Water Ports—These ports connect to your water pump or chiller to keep your laser tube cool and stable.
G. Air Intake—This port connects to your air assist to provide its pressurised air. Periodically check its filter to keep
it clear of any obstruction.
H. Air Assist Pump Port—If additional air assist is needed, remove the cover and connect your additional air assist
through this port.
5
