PPEVTEST
Specifications
General Specifications
Display Count : 4000 counts.
Overrange display : ">OL Reading" or ">-OL Reading"
Conversion Rate : 2 times / second
Dimensions (W x H x D) : 96mm x207mm x 54mm with holster.
Weight : 630g including battery.
Power requirement : 1.5V AA ALKALINE battery * 4.
Batteries Life :
R : Tester can perform at least 2500 R
2W
batteries at room temperature. These are standard tests of 1Ω with a duty cycle of 5
seconds on and 25 seconds off.
R : Tester can perform at least 800 R
4W
measurements with new alkaline batteries at room temperature. These are standard
tests of 1mΩ with a duty cycle of 5 seconds on and 25 seconds off.
R : Tester can perform at least 1000 R
INS
temperature. These are standard tests of 1 MΩ at 1000 V with a duty cycle of 5 seconds
on and 25 seconds off.
Installation Category : IEC/EN 61010-1, IEC/EN 61010-2-034
Compliance to EN 61557 : EN/IEC 61557-1:2021
EMC : EN 61326-1
CAT
It is applicable to test and measuring circuits connected directly to utilization
II points (socket outlets and similar points) of the low-voltage MAINS
installation.
It is applicable to test and measuring circuits connected to the distribution
III
part of the building's low-voltage MAINS installation.
It is applicable to test and measuring circuits connected at the source of the
IV
building's low-voltage MAINS installation
Environmental Conditions
Indoor Use
Pollution degree : 2
Operating altitude : 2000m (6562ft)
Operating temperature : 5°C ~ 30°C (≤80% RH),
Storage temperature : -20°C to 60°C, 0 to 80% R.H. (batteries not fitted)
Temperature Coefficient : 0.15 x (Specified accuracy)/°C, < 20°C or > 26°C .
Shock vibration : Random Vibration per MIL-PRFF Class 2
Drop Protection : 4 feet drop to the hardwood on the concrete floor.
resistance measurements with new alkaline
2W
resistance
4W
tests with new alkaline batteries at room
INS
EN/IEC 61557-2: 2021
EN/IEC 61557-4: 2021
Application field
30°C ~ 40°C (≤75% RH),
40°C ~ 50°C (≤45%RH)
