PPEVTEST
Measuring Insulation Resistance (Include PI/DAR/Timer)
The circuit under test must be completely de-energized.
1. Before starting the test: If the voltage detected is above 30V, ">30V" will appear on
the display. In this condition, the test is inhibited.
2. Set up the output voltage that can be adjusted precisely.
3. Lock mode : Press the "Lock" button >2sec to go into the Lock Mode (PI/DAR/Timer
only in lock mode). Then press the "TEST" button of the tester >2sec to start the test.
The test voltage will continue to be applied until the "TEST" button is pressed again.
CLIP4W
ISOPROBE
WARNING
10
EN
