Power Probe PPEVTEST User Manual page 14

PPEVTEST
Show the measured reading after the DAR test is completed
Show the measured reading after the Countdown Timer test is
completed
Using the Compare function
Before starting to test, select the comparative value in Setup mode, If the measured
value is better than the chosen compare value, the Pass indicator will be green,
otherwise, it will be red.
Comparison value of each mode:
R 0.5MΩ, 10MΩ, 20MΩ, 50MΩ, 100MΩ, 200MΩ, 500MΩ, 1000MΩ.
INS
R 0.5Ω, 1Ω, 2Ω, 3Ω, 4Ω, 5Ω, 10Ω, 20Ω, 30Ω, 40Ω.
2W
R 0.5mΩ, 1mΩ, 2mΩ, 3mΩ, 4mΩ, 5mΩ, 10mΩ, 20mΩ, 30mΩ, 40mΩ,50mΩ.
4W
