Textron JACOBSEN Turbo HR-9016 Parts And Maintenance Manual page 2

FORWORD
This manual contains
troubleshooting instructions and parts list for your new
Jacobsen machine. This manual should be stored with
the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the left frame rail. Jacobsen
recommends you record these numbers below for easy
reference.
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
UPS
Overnight
Qty. Part No.
4137894 Engine Oil Filter
5003370 Engine Air Filter
557619 Engine Fuel Filter
5003691 Hydraulic Charge Filter
5002693 Hydraulic Return Filter
Qty. Part No.
4136606 Safety and Operation Manual
4136607 Parts and Maintenance Manual
4136876 Engine Parts Catalog
© 2010, Jacobsen, A Textron Company/Textron Innovations Inc.
"All rights reserved, including the right to reproduce this material
or portions thereof in any form."
2
adjustment, maintenance,
the safety, operating,
Regular Mail
2nd Day
Description
Description
Litho In U.S.A. 2-2012
CHARLOTTE, NC
and
PRODUCT OF U.S.A.
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
Qty. Part No.
Service Support Material
Qty. Part No.
4171658 Service Manual
This
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
A Textron Company
PRODUCT OF U.S.A.
® 11524 WILMAR BLVD,
CHARLOTTE, NC 28273
A Textron Company
1-800-848-1636 (US)
