Textron JACOBSEN Turbo HR-9016 Parts And Maintenance Manual page 105

Item Part No.
–
1
2 1003573
3 1003575
4 339911
5 340065
339910
339897
6 1003604
7 1003577
8 339961
9 340143
339909
10 1003574
11 340144
339910
12 340215
339909
13 1003988
14 339966
> 15 339911
16 1003862
17 1003860
18 1003861
> 19 1004266
20 3006835
21 3009496
22 400336
23 446148
24 3007767
25 3008673
26 339979
339909
339897
27 340119
339909
28 4174140
29 4174141
30 365660
31 339909
32 339972
339908
339896
33 2810188
34 1003608
35 339910
36 473144
Qty. Description
1 Return Manifold
1 Hose, Pump to Return Manifold
1 Hose, 4WD Valve to Pump
1 O-Ring, SAE #10 Face Seal
1 Fitting, -8 ORFS x -6 ORB 90°
1 • O-Ring, -8 ORFS
1 • O-Ring, -6 ORB
2 Hose, Rear Wheel Motor Drain
1 Hose, Right Tee to 4WD Valve
2 Locknut, Bulkhead
1 Tee, -6 ORFS Swivel Branch
2 • O-Ring, -6 ORFS
1 Hose, Right Tee to Left Tee
1 Tee, -8 ORFS Swivel Branch
2 • O-Ring, -8 ORFS
2 Tee, -6 ORFS Bulkhead Run
3 • O-Ring, -6 ORFS
1 Manifold, Cooler Inlet
1 Locknut, Bulkhead
3 O-ring, SAE #10
1 Tube, Right Front Valve to Inlet
1 Tube, Right Side Valve to Inlet
1 Tube, Left Side Deck to Inlet
1 Hose, Cooler Inlet to Cooler
1 O-Ring, 1-3/4" O.D. x 1-1/2" I.D.
2 Flange Half, 1-1/4 SAE #20
4 Screw, 7/16-14 x 1-1/4 Hex Head
4 Lockwasher, 7/16 Heavy
1 Hose, Cooler to Return Manifold
2 Clamp, Constant Torque
2 Fitting, -6 ORFS x -6 ORB Straight
1 • O-Ring, -6 ORFS
1 • O-Ring, -6 ORB
1 Tee, -6 ORFS Swivel Run
2 • O-Ring, -6 ORFS
1 Hose, Tee to Return Manifold
1 Hose, Right Motor to Left Motor
1 Grommet
2 O-Ring, SAE #6 Face Seal
2 Fitting, -4 ORFS x -4 ORB Straight
1 • O-Ring, -4 ORFS
1 • O-Ring, -4 ORB
1 Hose, Front Deck Motor Case Drain
1 Hose, Back Pressure Valve Return
1 O-Ring, SAE #8 Face Seal
2 Tie, Wire Heavy
Serial Numbers/Notes
See 35.1
Not Shown
> Change from previous revision
