Performance Check
9, If the SignalScout RF analyzer is already in use, proceed to
step 10. Otherwise, power up the instrument as follows:
a. With the SignalScout RF analyzer turned off, plug the AC
adapter into the DC input connector.
b. Plug the AC adapter into a compatible power source,
c. Press [POWER] to turn the instrument on.
10. Press [DISP] to enter the Display menu.
a. Check that the words "DISPLAY MENU" appear in the upper
left portion of the screen.
b. Use the knob to turn the backlight off and on. Leave it set as
11. Press ([L.EVET] to enter the Level menu. Check that the five
function key assignments appear along the bottom of the screen,
as shown in Figure 5-4,
PILOTS ALL METER 5
1
Figure 5-4: Level menu function key assignments
12. Press [MEAS] to enter the Measurement menu. Check that the
function key assignments appear along the bottom of the screen,
as shown in Figure 5-5.
CIN HUM FM D/U FIELD
Figure 5-5: Measurement menu function key assignments
