EGR RollTrac RT0037 Installation Instructions Manual page 3

1
3
5
LHS MOUNT EXTRUSION QTY: 1
7
8
CANISTER STOP LH
QTY: 1
12
NUTS0293
M6 NUT CLIP
QTY: 2
16
MISC5222
FRONT DRAINAGE TUBE
QTY: 2
20
SCRW1001(SILVER)
SCREW M6x15
QTY: 12
RT0037
-- EGR Document ID#120520 v4
KIT CONTENTS - COMPONENT NUMBER AND QUANTITY
CANISTER ASM. QTY: 1
LHS RAIL QTY: 1
RUBBER EXTRUSION
QTY: 1
EGR RollTrac FITTING KIT IN BOX
9
CANISTER STOP RH
13
CLIP4038
M6 TAPPED PLATE
17
KIT037458
REAR DRAINAGE TUBE KIT
QTY: 2
21
SETUP JIG
QTY: 2
2022-07-08 16:26:14
2
4
6
QTY: 1
QTY: 2
22
RIVET
FAST0441
QTY: 4
Page 3 of 33
jhorwill --
FRONT COVER QTY: 1
RHS RAIL QTY: 1
RHS MOUNT EXTRUSION QTY: 1
11
10
SCRW0973 (BLACK)
MISC5512PC
M6 TAPPED PLATE
QTY: 8
14 15
SCRW1033 (BLACK)
SCREW M6X35MM
QTY: 4
18 19
MISC4041
DRILL JIG
QTY: 1
SCREW M6X15MM
QTY: 8
CONS70097
CABLE TIE
QTY: 10
SCRW0997 (BLACK)
SCREW M6x20
QTY: 12
Issue 4: 27/04/22
