EGR RollTrac RT0037 Installation Instructions Manual page 4

23
RUBBER
EXTRUSION
QTY: 2
Drill
Ratchet & Sockets
10mm
50/50
Isopropyl Alcohol/Water
DE-BURRING TOOL
RT0037
-- EGR Document ID#120520 v4
EGR RollTrac FITTING KIT COMPONENTS IN BAGS
EGR RollTrac FITTING KIT ADDITIONAL ITEMS
SPP UNIT
TOOLS REQUIRED - NOT SUPPLIED IN KIT
Hole Saw
Ø29mm (11/8")
Ø38mm (11/2")
Center Punch & Hummer
Allen Key 4mm
Allen Key 2.5 & 4mm
ANTI RUST
Rust Inhibitor
Rivet Gun
Ruler x2
2022-07-08 16:26:14
5PCS
Drill Stop
Drill Bits
Ø5mm (3/16")
Ø6mm (1/4")
Ø12mm (7/16")
Torque Wrench
5.5Nm (4ft-lb)
Tape Measure & Pen
Silicone
Page 4 of 33
jhorwill --
INSTALLATION
INSTRUCTIONS
Scissors
Side Cutters
3M Primer 94
(preferred) or
Silicone Spray
GLOSSARY:
1
Number inside a square indicate part number
1
Number inside circle indicate the sequence within a step
1
Number inside the hexagon indicate torque instruction
Issue 4: 27/04/22
OWNERS
MANUAL
Masking Tape
Fiberglass Tape
Black Cloth Tape
Soapy Water
equivalent
