- Page 1 6 Mirror Dishes Reflect Beam MOON FLOWER E-MF6 User Manual KEEP THIS MANUAL FOR FUTURE NEED...
- Page 2 INDEX STATEMENT ACCESSORIES SAFETY INSTRUCTION TECHNICAL SPECIFICATION CONTROL SYSTEM TROUBLE SHOOTING FIXTURE CLEANIG...
-
Page 3: Safety Instruction
STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual. - Page 4 user be sure that they also receive this. Unpack and check carefully that there is no transportation damage before using the unit. Before operating, ensure that the voltage and frequency of the power supply match the power requirements of the unit. It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
-
Page 5: Technical Specification
The equipment must be installed by professionals and it must be installed in a place where is out of the reach of people and no one can pass by or under it. TECHNICAL SPECIFICATION Control: Sound active, auto, Master/slave and DMX-512 modes ◆... -
Page 6: Control System
CONTROL SYSTEM 1.CONTROL PANEL Display Shows the various menus and selected functions Button MENU Selects the programming functions DOWN To go backward in the selected functions UP To go forward in the selected functions ENTER Confirms the selected functions Mains input Connection to the power supply. - Page 7 DMX Address Setting Press the MENU button to select . Press the ENTER button and the display will blink. Use the DOWN and UP buttons to choose the address from 1-255. Once the address has been selected, press the ENTER button to confirm. To go back to the functions without any changes press the MENU button again.
- Page 8 Channel Mode Press the MENU button to select . Press the ENTER button and the display will blink. Use the DOWN and UP buttons to select the Channel) mode, (8 Channel) mode , Once the mode has been selected, press the ENTER button to confirm. To go back to the functions without any changes press the MENU button again.
- Page 9 Auto-Test Press the MENU button to select . Press the ENTER button and the unit will run a self-test with its built-in programs. To go back to the functions without any changes press the MENU button again. Press and hold the MENU button for one second or wait for one minute to go back to the main menu.
- Page 10 button for one second or wait for one minute to go back to the main menu. Display normal mode is for floor standing the unit. Display inversion mode is for hanging the unit upside down. Auto-Test Press the MENU button to select .
- Page 11 button to confirm. To go back to the functions without any changes press the MENU button again. Press and hold the MENU button one second or wait for one minute to go back to the main menu. Please refer to the below diagram to address your first 4 units： Channel Unit 1 Unit 2...
- Page 12 250 - 255 Stop 000 - 005 Stop 006 - 126 Barrel movement forward fast -> slow Moon Wheel 3 127 - 128 Stop 129 - 249 Barrel movement backward slow -> fast 250 - 255 Stop 000 - 005 Stop 006 - 126 Barrel movement forward fast ->...
-
Page 13: Troubleshooting
TROUBLE SHOOTING Following are a few common problems that may occur during operation and some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of the power and the main fuse. B. - Page 14 Clean with a soft cloth using normal glass cleaning fluid or mild soapy water. Always dry the parts carefully. Clean the external optics at least every 20 days.
- Page 15 Factroy: No.31 Zhongxing Road Baiyun District Guangzhou,China +86-20-2904 6476 info@ricostagelight.com YouTube www.riukoe.com Facebook...
