Stinger SRX-JW18128 Manual

Introduction and Features
The SRX-JW18128 is a complete radio replacement kit with integrated climate control retention for select Jeep Wrangler
JL and Jeep Gladiator JT vehicles. All modules and cables are included to retain important features of the factory
system, including: steering wheel-mounted radio controls, factory reverse camera, USB ports, and AM/FM reception.
Data integration with the vehicle and the Stinger ix212 radio allows for the retention and addition of the following
features: vehicle performance gauges and information, climate controls, vehicle settings, factory amplifier control,
and forced camera activation. Simplified installation and setup menus allow direct programming of camera triggers,
steering wheel controls, and other settings of the radio and CH4A-JW18 interface. See Important Notes (next section)
for additional information.
Plug & Play wiring harnesses and cables allow for quick and easy installation without the need to cut or splice any
wiring.
Important Notes
We recommend reading this manual thoroughly to familiarize yourself with the entire process
1. D oes Not Retain:
Cluster Display Features
• Compass (when equipped with 7" or 8.4" screen)
• Clock
• Phone pop-ups
• Navigation pop-ups
Factory Amplifier Features
• Speed Controlled Volume
2. When connected properly, the USB port inside the center console will function for Apple Carplay/Android Auto, and all
other USB ports will be used for USB thumb drives and charging only.
3. Ensure that the CH4A-JW18, PL1, and RPA-HD1 modules have been updated to the latest version of firmware
before installing into the vehicle. Refer to the Updating Firmware section at the end of the manual for firmware update
instructions.
4. When connecting an HDMI streaming device to the RPA-HD1, use an HDMI extension cable to position it away from the
module to ensure proper functionality. We recommend placing the HDMI device in the glove box. Failure to follow the
directions may result in module malfunction.
terms OEM, Jeep®, Wrangler®, and Gladiator® all terms are used strictly for identification purposes only. It is
prior to beginning the installation.
Stinger Solutions is not affiliated with FCA US LLC. Jeep® is a registered trademark of FCA US LLC. The
not implied that any part listed is a product of, or approved by, Fiat Chrysler Automobiles.
for Jeep Wrangler JL and Jeep Gladiator JT Vehicles
Uconnect Features
• Uconnect Access Remote Start / Lock / Unlock
• SOS / Assist
• Vehicle Location Service
• WiFi-Hotspot
SiriusXM Guardian Services
• SiriusXM Radio
© 2024 Stinger
SRX-JW18128
Radio Replacement Kit
Rev: v1
Page 1
Date:011425
