TXGM19D10
Dual 10" Under Seat Subwoofer Enclosure
For GM Chevrolet Crew Cab Trucks
2019+ Sierra / Silverado 1500
2020+ Sierra / Silverado 2500 / 3500
INSTALLATION GUIDE
NOTE! Read this installation guide thoroughly before disassembling or modifying the
vehicle. Installation of this product requires technical skill, experience and specialized
tools. If in doubt, it's recommended to have it professionally installed by an authorized
Stinger or AudioControl Dealer.
A video installation guide is available at:
Advertisement
Table of Contents
Related Manuals for Stinger TXGM19D10
Summary of Contents for Stinger TXGM19D10
- Page 1 NOTE! Read this installation guide thoroughly before disassembling or modifying the vehicle. Installation of this product requires technical skill, experience and specialized tools. If in doubt, it’s recommended to have it professionally installed by an authorized Stinger or AudioControl Dealer. A video installation guide is available at:...
-
Page 2: Installation Notes
INSTALLATION NOTES The TXGM19D10 is designed to mount under the rear seat of GM Crew Cab Trucks. Some installation steps are more easily completed with a second person. Speaker wire is required. Final enclosure impedance: 2ohms. Recommended amplifier rating: 600-1,400 watts @ 2ohms. -
Page 3: Installation
INSTALLATION Step 1 Jack Lift up the Rear seat to expose the jack and the tool bag. Tool Bag Plastic Nut Step 2 (Skip this step if there is no storage tray) Locate the plastic nut holding the tool bag in place. - Page 4 INSTALLATION Step 3 Remove the nut located on the front side of the jack using a 10mm socket. Slide the P bracket onto the stud. Attach the nut back onto the stud leaving the P bracket able to slide for assembly later.
- Page 5 INSTALLATION Step 6 Reinstall the tool bag with spring clip onto the middle stud, using the plastic nut. Plastic nut Tool Bag Step 7 Place the speaker enclosure in the vehicle with the rear of the enclosure facing the back seat. Route speaker wire to the rear of the enclosure and connect using either the Push Terminals or the...
- Page 6 INSTALLATION Key hole M6 Bolt Step 8 Install the 2 M6 hex bolts into the back of the enclosure. Slide the enclosure so the 2 bolts line up with the key holes D and P brackets. Once the enclosure is in place, push down on the enclosure.
- Page 7 COMPLETED Step 9 Crank up the volume.
-
Page 8: Specifications
Limited Warranty Stinger warrants this product to be free of defects in materials and workmanship for a period of one (1) years from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Stinger dealer in the United States of America only. - Page 9 Complimentary Layout Page (tape measure and calculator not included)
- Page 10 Complimentary Layout Page (tape measure and calculator not included)
- Page 11 Complimentary Layout Page (tape measure and calculator not included)
- Page 12 Mobile audio support: Phone: 425-777-7723 Email: support@audiocontrolmobile.com As Technology advances, AudioControl reserves the right to © 2024 Stinger. All rights reserved. AudioControl is a Stinger Technical Support Phone: 727-592-5991 Email: support@stingersolutions.com © 2024 AAMP Global. All rights reserved. | IG-TXGM19D10 REV 091024...
