Product overview Product overview The C6030 Industrial PC is part of the series of ultra-compact industrial PCs for space-saving control cabinet installation. It is a high-performance device. Thanks to the available processors, the industrial PC can be used for the following applications, among others: •...
Product overview Structure Fig. 1: Structure – basic configuration Table 1: Key: C6030 structure Component Description Protective conductor connection PE Low-resistance protective earthing and functional earthing of the industrial PC Power supply (X101) Connection of the power supply and external wiring of the industrial PC...
Product overview Interface description In the basic configuration, the C6030 includes the following interfaces: • Power supply (X101) • Ethernet RJ45 (X102-X105) • USB (X106-X109) • DisplayPort (X110, X111) 3.2.1 Power supply The industrial PC is supplied with a nominal voltage of 24 V. The 2x2-pin voltage socket (X101) is used for connection to the power supply and the external wiring of the industrial PC.
Product overview 3.2.2 Ethernet RJ45 The C6030 has four Gigabit LAN ports (X102-X105). The 100Base-T, 1000Base-T and 2500Base-T Ethernet standards enable the connection of corresponding network components and data rates of 100/1000/2500 Mbit/s. The required speed is selected automatically. The RJ45 connection technology with twisted-pair cables is used. The maximum length of the cable connection is 100 m.
Product overview Table 5: LED meaning speed 100/1000 Mbit/s Mbit/s Lights-up orange 1000 Lights up green Table 6: LED meaning speed 100/1000/2500 Mbit/s Mbit/s 1000 Lights-up orange 2500 Lights up green Version: 1.8 C6030...
B and USB ports C and D are each protected by a common overcurrent detection. If an overcurrent occurs at one of the ports, the two jointly protected USB ports are switched off. For the device generation C6030-0070, USB port X108 is only compatible with USB 3.0. X106...
The industrial PC has two DisplayPorts (X110, X111) that enable connection of devices with DisplayPort. It facilitates transfer of image signals. In addition, DVI signals can be transferred via an adapter. Please order it from your Beckhoff sales team, quoting order identifier C9900-Z468 adapter cable DisplayPort to DVI, 40 cm.
Moderate signal quality Green Steadily lit Good signal quality Steadily lit Poor signal quality 3.3.2 PWR LED The PWR (power) LED indicates the status of the power controller. The colors and flashing intervals have the following meanings: C6030 Version: 1.8...
Flashing Checksum error during the I2C transmission in the bootloader Cyan Flashing (2 s) contact Beckhoff Service 3.3.3 HDD LED The HDD LED indicates the activity of the storage medium. The colors and flashing intervals have the following meanings: Table 12: Meaning of the HDD LED...
Product overview Name plate The name plate provides information on the equipment fitted to the industrial PC. The name plate shown here serves only as an example. xxxxxxxx xxxxxxxx xxxxxxxxxxxx xxxxxxxxxxxx xxxxxxxxxxxx xxxxxxxxxxxx Fig. 7: Name plate C6030 Version: 1.8...
4. Check the contents for visible shipping damage. 5. In case of discrepancies between the package contents and the order, or in case of transport damage, please inform Beckhoff Service (see Chapter 10.1 Service and Support [} 43]). Version: 1.8 C6030...
Order identifier Version C9900-M668 Mounting plate on the side wall, instead of the standard mounting plate C9900-M669 Mounting plate for lateral mounting of the C603x, single part, not mounted Also see about this 2 Technical data [} 42] C6030 Version: 1.8...
PC as required to align the connections in the control cabinet. You have the following mounting options, which are shown in Fig. 10: • Connections point upwards (A) • Connections point downwards (B) • Connections point to the right (C) • Connections point to the left (D) Version: 1.8 C6030...
80,6 Fig. 12: Mounting plate, side panel 4.2.3 Installation in the control cabinet When installing in the control cabinet, note that there must be 5 cm of free space around the device for air circulation. Mounting via mounting plates Version: 1.8 C6030...
1. Place the fastening screws in the drill holes in the rear panel of the control cabinet. 2. Hang the PC on the screws at the marked points of the mounting plate (see Fig. 13). 3. Tighten the fastening screws. ð You have successfully installed the industrial PC in the control cabinet. C6030 Version: 1.8...
Peripheral devices connected to the device with their own power supply must have the same potential for the PE and "0 V" conductors as the control panel (no potential difference). 230 V 24 V Grounding busbar Fig. 14: Wiring example Version: 1.8 C6030...
PC is installed. Use wires with a cross-section of at least 4 mm or a flat conductor for the ground connection, as the circumference of the conductor should be as large as possible. Fig. 15: Protective conductor connection PE C6030 Version: 1.8...
3. Screw the power supply plug to the power supply socket of the industrial PC. 4. Connect the PC to your external 24 V power supply. 5. Switch on the 24 V power supply. ð You have connected the power supply. Version: 1.8 C6030...
The UPS software components with the corresponding drivers must be installed on the PC in order to operate the power supply unit as a UPS. The software components and drivers are already installed on delivery of the PC with operating system. If they are not, you have to install the installation package Beckhoff UPS yourself.
• User name: Administrator • Password: 1 You also have the option of using the Beckhoff Device Manager to remotely configure the device via a web browser. More detailed information is available in the Beckhoff Device Manager manual. First start Beckhoff Device Manager When your device is booted for the first time, the Beckhoff Device Manager also starts automatically for the first time.
Secure passwords Strong passwords are an important prerequisite for a secure system. Beckhoff supplies the device images with standard user names and standard passwords for the operating system. It is imperative that you change these. Controllers are shipped without a password in the UEFI/BIOS setup. Beckhoff recommends assigning a password here as well.
5. Make a note of the wiring of all data transmission cables if you want to restore the cabling with another device. 6. Disconnect all data transfer cables from the industrial PC. 7. Finally, disconnect the ground connection. ð You have disconnected the cables and the power supply. Version: 1.8 C6030...
• Electronic parts such as fans and circuit boards must be disposed of in accordance with national electronic scrap regulations. • Stick insulating tape over the poles of the CR2032 battery on the motherboard and dispose of the battery via the local battery recycling. C6030 Version: 1.8...
• Only use a vacuum cleaner to clean the PC. The industrial PC does not have to be switched off for this. • Never use compressed air to clean the PC. • Maintain an ambient temperature range of 0 °C to +55 °C. Version: 1.8 C6030...
NOTICE Use of incorrect spare parts The use of spare parts not ordered from Beckhoff Service can lead to unsafe and faulty operation. • Only use spare parts that you have ordered from Beckhoff Service. Beckhoff devices are manufactured from components of the highest quality and robustness. They are selected and tested for best interoperability, long-term availability and reliable function under the specified environmental conditions.
Using any other battery may cause fire or explosion. • Only replace the battery with battery type R/C (BBCV2), order number RC2032, nominal voltage 3 V. • When replacing the battery, make sure that the polarity is correct. Version: 1.8 C6030...
5. Push the high side of the battery down into the battery holder (see fig. 20). ð You have successfully replaced the battery. Battery disposal To dispose of the battery, remove it, tape off the poles and put it in the battery disposal. C6030 Version: 1.8...
If you want to exchange a storage medium according to Beckhoff's recommendation, you must copy the data from the old to the new storage medium. You can use the Beckhoff Service Tool (BST) for this purpose. BST is a graphical backup and restore program for PCs with a Windows operating system. You can create an image of your operating system and use it to back up the operating system.
The device may be damaged if the wrong type of fan is installed. • Only replace the fans with replacement fans from Beckhoff Service. The fans ensure optimal cooling of the device. Order replacement fans only from Beckhoff. Please get in touch with your Beckhoff sales contact.
Page 40
7. Attach the fan to the fan plate with the two Torx screws and a tightening torque of approx. 0.5 Nm. ð You have successfully replaced the fan. The old fan must be disposed of in accordance with the national electronic waste regulations. Version: 1.8 C6030...
Measures No function of the device No power supply to the device Check the power supply cable Other cause Call Beckhoff Service The device does not boot fully BIOS setup settings are incorrect Check BIOS setup settings (load defaults) Other causes...
Technical data Technical data Table 17: Technical data Product designation C6030 Dimensions (W x H x D) 132 x 133 x 76 mm, without mounting plate Weight approx. 1460 g without mounting plate approx. 1700 g with mounting plate Supply voltage 22-30 V (24 V power supply unit)
