Initial Setup Continued
3� See Figure 4� Press the START (green) switch�
Lamp (white) will illuminate and power is
supplied to the pendant�
4� See Figure 5� Using the pendant, press the
POWER rocker switch to ON�
5� See Figure 6� Press and hold the PUMP RUN
switch� The pendant will start and run the pump
motor as long as the pump run switch is pressed�
Switch will automatically return to OFF position
when switch is released and pump motor will
turn off�
6� See Figure 4� Press the STOP (red) switch to
remove power from the pendant�
© SPX FLOW, Inc.
1
Item
1
2
3
Figure 4. Power Switch
Figure 5. Power ON
Figure 6. Pump RUN
7
3
2
Description
Stop (Red)
Lamp (White)
Start (Green)
Form No.
1000591
Rev. 2 May. 30, 2022
