DESCRIPTION
PE8 SERIES ELECTRIC/HYDRAULIC PUMPS
Description : The PE8 series hydraulic pumps are designed to have a maximum of 1500 bar (21,750
psi) at a flow rate of 131 cc/min (8 cu. in/min). All pumps come fully assembled, less fluid, and ready
for work.
Universal Motor
The universal motor pump shown in Figure 1, is
available in a 0�4 kW (1/2 hp)� The motor is in single-
phase configuration.
The universal motor offers the ability to operate at low
voltage� This motor has elevated acoustic output as
noted on the product labels� This motor is ideal for long
service, fixed applications.
The 0�4 kW (1/2 hp), 110/115 or 220/230 VAC, 50/60
Hz single phase motor starts under load, even at
reduced voltage� Current draw can be up to 11 Amps
at 115V (15 Amp fuse) and 5�5 Amps at 230V (10
Amp fuse) and the sound level is rated at 82-86 dB�
Operating temperatures range is -25°C to +50°C (-13°F
to 122°F)�
If temperatures are at extremes of the operating range,
it is recommended to use hydraulic fluids that are rated
for those temperatures� The weight can be up to 50lbs
(23kg)�
Figure 1. PE8 Series
